Summary of Contents for socomec Sirco MV 100

  • Page 1 _________ l � -' -------- - - Универсальный выключатель нагрузки Socomec Sirco MV - руководство пользователя. Юниджет Постоянная ссылка на страницу: https://www.uni-jet.com/catalog/sistemyi-kommutaczii,- kontrolya-i-zashhityi/vyiklyuchateli-nagruzki/socomec-sirco-mv.html...
  • Page 2 LOAD BREAK SWITCH SIRCO MV 100 - MV 125 - MV 160 Instruction sheet Notice d'utilisation Instrucciones de servicio Must be used for side operation with DIN rail 5000 0041 5000 0051 IS 533746 14919111 22003110 22004110 14939111 22003012 22004012...
  • Page 3 Max: 2 x 2,5 mm² pozidriv 1 7.08 lb.in 0,8 Nm 10 mm / 0.39 in position pre-close + pre-break STEP 1 STEP 2 4.4 lb.in 0,5 Nm Pozidriv 1 13.3 lb.in 1,5 Nm Pozidriv 2 0.24 in 6 mm L = X + 1.38 in L = X + 35 mm STEP 2...
