Teknion Projek Adjustment Features & Instruction

SEAT HEIGHT ADJUSTMENT
Seat height can be adjusted by
pulling outward on the button
below the seat on the right hand
side. When this button pulled, the
weight of the body will cause the
seat to lower, and releasing it stops
the seat at the desired height.
Pulling outward on the button
with no weight on the seat allows
it to rise.
3D ARM PIVOT ADJUSTMENT
To pivot the arm cap, depress the
auto safety lock button on the
outside of the armrest and pivot
180˚ degrees to desired position.
Release the button to lock in place.
BACK TILT ADJUSTMENT
Turning the grip found under the
left side of the seat limits the back
tilt travel and locks the back. Travel
is limited on 3 positions with back
lock in the upright position.
projek adjustment features & instruction
To adjust the seat depth, pull
outward on the button below the
seat on the left-hand side and
simultaneously lift your weight
from the seat while sliding the seat
forward or backward. Release
button to lock the seat in place.
To adjust the arm height, press the
button below either arm rest to
raise or lower it to the desired
position. Release the button to lock
in place.
Fine tune the weight balanced
tension by rotating the dial located
below the seat centre to suit
personal preference.
SEAT DEPTH ADJUSTMENT
ARM HEIGHT ADJUSTMENT
TILT TENSION ADJUSTMENT
