- Page 1 Users’ Manual SDI 10-Screen Multiview Model: MVP9110 VER 10 Website: www.devicewell.com Email: support@devicewell.cn...
- Page 2 Precautions To ensure the reliability, use and safety of the equipment, please observe the following when installing, using and maintaining: Before the device is powered on, it is necessary to check to ensure that the chassis is well grounded to prevent electrostatic discharge from the chassis and endanger the equipment and personal safety, and to provide good shielding effect.
-
Page 3: Table Of Contents
Contents 1. Product Introduction ......................1 1.1. Product Overview ..................... 1 1.2. Main Functions ......................1 1.3. Product Parameters ....................2 1.4. Standard List ......................3 2. Operation and Function Description ................... 4 2.1. Equipment operation ....................4 2.2. Multi-screen Mode Description ................4 2.2.1. - Page 4 2.6. 10-screen character setting control software description ........12 2.6.1. Open the software ..................13 2.6.2. Controlling device ..................13 2.6.3. Right click menu bar ..................14 2.6.4. Single screen display function ..............16 2.6.5. Display screen switching function ............... 16 2.7.
-
Page 5: Product Introduction
◆ Chinese and English character overlay (character color can be changed) ◆ Input port: SDI × 8; HDMI × 2; ◆ Output port: SDI × 2; HDMI × 3 ◆ Input support matrix switching function ◆ SDI HD/SD Adaptive Website: www.devicewell.com Email: support@devicewell.cn... -
Page 6: Product Parameters
SDI HD serial digital video signal Connector BNC complies with IEC169-8 Reflection loss >15dB 5MHz~3GHz Signal amplitude 800mV± 10% 75Ω Impedance SDI Output Up/Down time 0.6ns± 100ps DC offset 0V± 0.5V Clock recovery Auto output optional Overshoot <5% Jitter <0.2Ul Website: www.devicewell.com Email: support@devicewell.cn... -
Page 7: Standard List
0℃~50℃ without condensation Temperature Storage Temperature -20℃~75℃ Working Humidity 20%~70%RH Storage Humidity 0%~90%RH, No condensation 1.4. Standard List Multiview main part AC power cord x 1 Control software x1 User Manual x1 Website: www.devicewell.com Email: support@devicewell.cn... -
Page 8: Operation And Function Description
(5) Use the manual button to select the input and output ports. (6) Rear panel interface description: ① SDI× 2(Multi-screen output) ② HDMI x3(Multi-screen output) ③SDI× 10 input ④RS422 interface ⑤REST Reset ⑥Power Indicator ⑧AC 100 – 240V ⑦Network and USB interface 2.2. Multi-screen Mode Description Website: www.devicewell.com Email: support@devicewell.cn... -
Page 9: 1-Screen Mode
1-screen mode 2.2.1. Website: www.devicewell.com Email: support@devicewell.cn... -
Page 10: 4-Screen Mode
2.2.2. 4-screen mode 2.2.3. 6-screen mode Website: www.devicewell.com Email: support@devicewell.cn... -
Page 11: 8-Screen Mode
2.2.4. 8-screen mode 2.2.5. 9-screen mode Website: www.devicewell.com Email: support@devicewell.cn... -
Page 12: 10-Screen Mode
OUT + 5), you can also switch all the way at the same time. To multi-channel display, IN 2 OUT 1, 2, 3, 4..If you want to switch 10 channels, press 10+ first, then press 0. 2.3.2. Full Panel Website: www.devicewell.com Email: support@devicewell.cn... -
Page 13: Mode
When Mode is switched, the LCD will display the current multi-picture status, and the number in the small grid represents the current input channel number. When you perform a software upgrade, the status of the upgrade and the version information of the program are displayed. 2.5. Function capture Website: www.devicewell.com Email: support@devicewell.cn... -
Page 14: Single-Screen Zoom Function
2.5.1. Single-screen zoom function Audio video can be output at the same time, characters can be added arbitrarily, drag in different positions. 2.5.2. 4- screen resolution change Website: www.devicewell.com Email: support@devicewell.cn... -
Page 15: 6-Screen No Signal Input
2.5.3. 6-screen No signal input Any base map can be added, such as: company group photo logo 2.5.4. 8- Screen Website: www.devicewell.com Email: support@devicewell.cn... -
Page 16: 10-Screen
2.5.5. 10-screen 2.6. 10-screen character setting control software description Website: www.devicewell.com Email: support@devicewell.cn... -
Page 17: Open The Software
The software version of this example is: ItemMove_16P_PcSet_r_v1.0.3.0_20170425.exe, the software 10 screen is shared with our 16 screens. ItemMove_16P_PcSet_r_v1.0.3.0_20170425.exe，该软件 10 画面与本公司 16 画面共用 2.6.2. Controlling device The control button area is roughly divided into two parts, as shown below Website: www.devicewell.com Email: support@devicewell.cn... -
Page 18: Right Click Menu Bar
(5) UMD button, click to turn UMD display on or off (6) Change the face switch button, click to switch the screen display mode 2.6.3. Right click menu bar The contents of the entire right button are as shown in Picture 3 below. Website: www.devicewell.com Email: support@devicewell.cn... - Page 19 Only English letters and Arabic numerals can be entered in the input box, and try to be within 16 characters. Click “Change” and the following words will appear in the schematic area. At this point, the mouse moves to the green area, and the mouse changes to the shape of Website: www.devicewell.com Email: support@devicewell.cn...
-
Page 20: Single Screen Display Function
Y output” mode: “X” indicates the input channel number of 1~10, “Y” indicates the output channel number of the current multi-screen, “Enter” Replaced by MON on the keyboard, "out" is replaced by CAM on the keyboard (example: the current picture is 10 Website: www.devicewell.com Email: support@devicewell.cn... -
Page 21: Menu Usage And Lcd Display Instructions
2.7.2. Menu After pressing the knob on the front panel, enter the main menu as shown below. Main Menu System Setting Network Setting Display Setting Audio Setting Device Info. Website: www.devicewell.com Email: support@devicewell.cn Exit... - Page 22 The setting method is the same as above. 3) Backlight time: You can freely adjust the time to adjust the backlight constant according to your own use. 4) Reset Settings: This option restores the factory settings. After setting, all settings including Website: www.devicewell.com Email: support@devicewell.cn...
- Page 23 If it is not saved, the setting will be invalid. 2.7.2.4. Display settings Select the display setting and press the knob to enter the display setting screen, as shown below. Website: www.devicewell.com Email: support@devicewell.cn...
- Page 24 Press the knob → select the channel under the knob to be controlled → select display enable press the knob → can select whether; turn on the channel screen display, or close the channel The screen is displayed. Website: www.devicewell.com Email: support@devicewell.cn...
-
Page 25: Tally Function
2.10. Dual power supply This device supports dual power supply. It can be used together with two power supplies or one power supply. One power supply is displayed on the LCD panel. The normal status is Website: www.devicewell.com Email: support@devicewell.cn... -
Page 26: Failure And Maintenance
The company guarantees that the process and materials of the product are not defective within 12 months after purchase from the company or its authorized distributors, under normal use and service support. We offer a one-year warranty after sale. Website: www.devicewell.com Email: support@devicewell.cn...
