DeviceWell MVP9110 User Manual

Sdi 10-screen multiview
Hide thumbs Also See for MVP9110:
Table of Contents

Advertisement

Quick Links

Download this manual
Users' Manual
SDI 10-Screen Multiview
Model: MVP9110
VAR 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVP9110 and is the answer not in the manual?

Questions and answers

Related Manuals for DeviceWell MVP9110

Summary of Contents for DeviceWell MVP9110

  • Page 1 Users’ Manual SDI 10-Screen Multiview Model: MVP9110 VAR 2.0...
  • Page 2 Precautions To ensure the reliability, use and safety of the equipment, please observe the following when installing, using and maintaining. Before the device is powered on, it is necessary to check to ensure that the chassis is well grounded to prevent electrostatic discharge from the chassis and endanger the equipment and personal safety, and to provide good shielding effect.

  • Page 3: Table Of Contents

    Contents 1. Product Introduction ......................1 1.1. Product Overview ..................... 1 1.2. Product parameters ....................2 1.3. Standard configuration list ..................3 2. Operation and Function Description ................... 3 2.1. Equipment operation ....................3 2.2. Multi-screen Mode Description ................4 2.2.1.

  • Page 4: Product Introduction

    1. Product Introduction Product Overview 1.1. This is a professional-grade SDI picture splitter that supports 10-CH SDI inputs, 2-CH HDMI inputs, and 2-CH AV inputs. 2-CH SDI+3-CH HDMI output. You can change the display resolution to 1080i50 / 60, 1080p25 / 30 or even more using the front panel keyboard. The device is a multi-screen splitter with 10-way matrix switching.

  • Page 5: Product Parameters

    Product parameters 1.2. Name SDI HD 10-Screen Multiview Input Signal SDI HD serial digital video signal Rate 143Mbps~2.97Gbps Connector BNC complies with IEC169-8 SDI Input Reflection loss >15dB 5MHz~3GHz Signal amplitude 800mV±10% Impedance 75Ω 100m Belden 1694A HD Balance 200m Belden 8281A HD Output Signal SDI HD serial digital video signal Connector...

  • Page 6: Standard Configuration List

    Standard configuration list 1.3.  Matrix Master  AC power cord x 1  Control software x1  User Manual x1 2. Operation and Function Description Equipment operation 2.1. Note: Please use the following installation sequence. If the installation sequence is not followed correctly, the device may not work or work abnormally .

  • Page 7: Multi-Screen Mode Description

    Multi-screen Mode Description 2.2. 1-screen mode 2.2.1. 4-screen mode 2.2.2. 6-screen mode 2.2.3.

  • Page 8: 8-Screen Mode

    8-screen mode 2.2.4. 9-screen mode 2.2.5. 10-screen mode 2.2.6.

  • Page 9: Keypad Operation Instructions

    Keypad Operation Instructions 2.3. 2.3.1. Channel switching operation Switching operation can be performed according to the input signal and the multi-screen window number. IN x OUT y (such as switching the 2nd signal to the 5th display, IN + 2 + OUT + 5), you can also switch all the way at the same time.

  • Page 10: Char

    2.3.6. Char Switch between displaying or hiding the characters of all channels. LCD function 2.4. When Mode is switched, the LCD will display the current multi-picture status, and the number in the small grid represents the current input channel number. When you perform a software upgrade, the status of the upgrade and the version information of the program are displayed.

  • Page 11: Umd Module

    2.4.3. UMD module Click the UMD icon to enter the module. The UMD module can open and close the screen characters, and can customize the characters of each window. After entering in the corresponding window bar, press ENTER to save. Note: the input field supports a maximum of 10 characters.

  • Page 12: Setting Module

    2.4.5. SETTING Module Click the SETTING icon to enter the module, which has the following functions: 1）Audio main switch, turn on and off the audio main switch; 2）Sound input source, select the channel to input the sound source; 3）Output resolution, switching output resolution; 4）Screen display switch, turn on and off, input resolution characters;...

  • Page 13: Menu Usage And Lcd Display Instructions

    Menu usage and LCD display instructions 2.5. 2.5.1. Startup LCD status display After power on, you can see the status of power supply, internal temperature of chassis, channel status and time on the LCD panel. If the dual power supply fails, a power supply icon in the figure above will turn red.

  • Page 14: Menu

    2.5.2. MENU Press the knob on the front panel to enter the main menu, as shown in the following figure. 2.5.2.1. How to use the knob 1) Rotate clockwise to select downward. 2) Counterclockwise is the up selection. 3) When selected, the font background is blue. 4) Press to confirm.
  • Page 15 System settings include language settings, LCD screen brightness settings, backlight time and reset settings 。 1) Language setting supports two languages, simplified Chinese(简体) and English. Setting method: turn the knob to language selection → press the knob → turn the knob to select the language to be set → press the knob. 2) Screen brightness setting: the brightness of the LCD panel can be adjusted through the knob.
  • Page 16 In the network settings, you can set the IP, subnet mask and network management of the device. Set the IP address: press the knob after selecting the IP address → you can set the first segment PICTURE 192 of the IP. You can turn the knob to increase and decrease the number →...
  • Page 17 Display settings: 1) Sets the font color and background of the selected channel UMD. 2) Sets the font color and background for the selected channel resolution. 3) Turns on or off the screen output of the selected channel. Setting method: Custom font color and background color: rotate the knob to select the channel and press the knob →...

  • Page 18: Tally Function

    2.5.2.5. audio setup Select the display setting and press the knob to enter the display setting screen, as shown below. The audio setting option can turn on or off the specified channel audio Setting steps: ① Turn the knob to the audio source channel and select the channel to be controlled.

  • Page 19: Common Faults And Solutions

    3.3. 3.3.1. Guarantee information Devicewell provides a 12-month warranty for this product from the date of purchase. If the product fails during the warranty period, devicewell can provide free repair or replacement of parts for the product, and replace the defective product if necessary. In order to ensure that users...

  • Page 20: Appendix

    3. Repair the damage or failure caused by the use of parts not produced or provided by devicewell; 4. Carry out maintenance and repair for products modified or assembled with other products (the time required for maintenance and repair or maintenance difficulty will be increased after product modification or assembly).
