OPERATING THE AUTO-SCRUBBER

OPERATION

The controls have clear symbols for the function they control.
• Turn the key for main switch (B1).
• Turn on the different applications in the
following order by pressing switches:
1. Push button for solution pump (B6), if
necessary adjust water flow (C1)
2. Push button for brush motor (B5)
3. Push button for vacuum motor (B4)
• By pulling the brush operation lever (A14) the
machine will start moving forward.
• Drive the first 10 to 15 feet to test the water
flow as well as the chosen brushes or pads
and make sure
requirement to properly clean the floor.
• At the same time check the vacuuming
performance. If
squeegee angle (E3).
IMPORTANT INFORMATION
• When the machine is not being operated,
immediately turn of the brush in order to
avoid damage to floor surface.
• If either liquid or foam leaks from machine
unintentionally, immediately switch off the
machine.
• Brush wear is automatically adjusted for by
the weight of the entire brush support.
• In case of foam in the recovery tank add
defoamer to prevent foam entering the tube
of the vacuum motor.
REPLACING DISC BRUSHES OR PAD DRIVER
Tilt the machine backwards and place it on the
kickstand for replacing brushes (F1) underneath
the front of the machine. The kickstand is on the
front left side (seen from operators view).
All disc brushes and pad holders are removed
by turning the left one clockwise and right one
counter-clockwise and
downwards.
To insert the brushes or pad holders, place the
pins on the brushes into the holes of the drive
Safety, Operation and Maintenance Manual for Falcon (RA 530 B); Version 1.0
that these meet the
necessary adjust the
by pulling them
• If the auto scrubber should run forward too
fast or too slow it can be regulated with the
screw for adjusting the brush pressure (F2).
The screw is at the front on the right side
(seen from the operator's position). The
adjustment can be set between a pressure of
35 and 70 lbs.
Turning the screw upwards
Turning the screw downwards
• Check filling level regularly and empty
recovered water in time. Make sure enough
water is dispensed whilst running the
brushes or pads as these should never be
run dry.
• Use brushes, pads and accessories as
described in this operations manual. Failure
to comply with this can be hazardous.
disc underneath the machine. Fix the brushes or
pad holders by quickly turning the left one
counter-clockwise and the right one clockwise.
Important
• The direction of rotation of the left brush is
clockwise and the right brush counter-
clockwise.
• The brush pressure can be adjusted with the
screw for adjusting the brush pressure (F2).
Decreases
pressure
Increases
pressure
