6 SOFTWARE-DEPENDENT
FUNCTIONS
6.1

STANDARD FUNCTIONS

This section describes the software-dependent functions that can be performed by Comfort and Basic User
Handsets alongside the DYNAMIC MOTION system. If your DYNAMIC MOTION system will be controlled by
a different User Interface, consult that product's Operating Manual for instructions and safety advice.
6.1.1

LOW SPEED AREA

During movement, this function causes a reduction in speed before the following positions are reached:
• Maximum and minimum Table Top height
• All saved positions (e.g. Memory Positions, Container Stop Position, etc.)
Risk of minor or moderate injury through crushing
Collision Detection (ISP) is inactive in the Low Speed Area. This may lead to minor or
CAUTION
moderate injury through crushing.
• Ensure that no persons or objects are in the table's range of motion

6.1.2 SAFETY AREA

This function causes a safety stop at a defined Table Top height, which is set through the product's software.
INFO
You cannot save table positions that fall within the safety area.
Risk of minor or moderate injury through crushing
Collision Detection (ISP) is inactive in the Safety Area. This may lead to minor or mod-
CAUTION
erate injury through crushing.
• Ensure that no persons or objects are in the table's range of motion
You can move the table into the safety area as follows:
1. Press and hold the DOWN Key
▸ The Table Top is adjusted to the start of the safety area
▸ The Table Top stops moving when the safety area is reached
2. Press the DOWN Key again to move into the safety area
6.1.3 CONTAINER STOP AND SHELF STOP POSITIONS
These features can limit the movement area of the Table Top (e.g. if a container is below the table or a shelf
is above it). Container Stop Positions become the new lowest end position, Shelf Stop Positions the highest.
Container Stop Positions can only be saved in the lower half of the movement area, Shelf
INFO
Stop Positions in the upper half. You must set each position separately.
Proceed as follows to save a Container Stop / Shelf Stop Position with a Comfort Handset:
1. Press the UP or DOWN Key to move the Table Top to the desired position
2. Press and hold the SAVE Key for 10 seconds
SAVE
▸ The Container Stop / Shelf Stop Position is saved
Proceed as follows to save a Container Stop / Shelf Stop Position with a Basic Handset:
1. Press the UP or DOWN Key to move the Table Top to the desired position
2. Press and hold the UP Key and DOWN Key for 10 seconds.
▸ The Container Stop / Shelf Stop Position is saved
Proceed as follows to delete a Container Stop / Shelf Stop Position with a Comfort Handset:
