LOGICDATA DYNAMIC MOTION System Manual page 17

8.2 SYSTEM INFORMATION
8.2.1 DMUI-TOUCH-B-UD / DMUI-EASY2MOVE
When a DMUI-TOUCH-B-UD or DMUI-EASY2move Handset is installed alongside the DYNAMIC MOTION sys-
tem, system information is communicated via flashes of the LED Signal Light. Possible signals are as follows:
Signal
No Light System operating normally
System not connected
Red Light Blinking System Error Warning
Green Light Blinking System Start-up
Reset in Progress
Duty Cycle Exceeded
Collision Detected (ISP)
Green Light Flashing Position Reset Required.
Rapidly
Do not operate the DYNAMIC MOTION system if problems persist. Contact LOGICDATA
NOTICE
for further information.
8.2.2 DMUI-TOUCH-C-FX
When a DMUI-TOUCH-C-FX Handset is installed alongside the DYNAMIC MOTION system, error messages
are displayed on the digital display panel. These are as follows:
Signal
The display shows "Hot".
The display shows "ISP".
The display shows "Con",
then "Err".
DYNAMIC MOTION SYSTEM - SYSTEM MANUAL // PAGE 17
Message
Operate the DM System as normal.
See Configuration Handbook for instructions.
Release all Keys and wait for 5 seconds. Then, try
to repeat the action again.
Disconnect all components from the Power Hub.
Disconnect the Power Hub from the Mains.
Check the Power Hub for overheating. Let cool if
necessary.
Check all connections and reconnect the system.
If problem persists: Perform a Position Reset
Procedure (Chapter 4.7). Contact LOGICDATA
Wait until the LED has stopped blinking to
continue.
Do not press any buttons.
Remove the obstruction from the Table System.
Remove unnecessary loads from the Table Top
Operate the DM System as normal.
Perform a Position Reset Procedure (Chapter
4.7).
Message
Overheating protection has
been activated.
The system has recognized a
collision.
The system has recognized a
connection error.
Required Actions
Required Actions
Wait for the overheated components to
cool.
Release all Keys and wait for the Drive
Back function to be completed.
Release all Keys and wait for 5 seconds.
Then, try again.
Disconnect the Power Hub from the
Mains. Then, disconnect System from the
Power Hub. Reconnect the system again,
then operate the DM System as normal.
