CHARGER LAYOUT
BATT TYPE/STOP
DEC/INC
START/ENTER
To select main program
To select sub program
To resume or start the
To stop operation
To alter the value
operation
Input Power Cable
Charging lead
Individual cell
DC11-18V
connector
connector port
4mm banana female
Input Power Cable
3-pin port for tem-
AC100-240V
perature sensor
7
