- Page 1 LiPo LiHV LiFe LiIon SCAN QR-CODE • Mode d’emploi en Francais NiMH NiCd • Nederlandstalige handleiding 2-16 • Betriebsanleitung Deutsch 100-240V 19-26V • Instruction Manual English INSTRUCTION MANUAL...
-
Page 2: Warnings And Safety Notes
WARNINGS AND SAFETY NOTES These warnings and safety notes are particularly important. Please follow the instructions for maximum safety; otherwise the charger and the battery can be damaged or at worst it can cause a fire. Also read the chapter before you begin. •... - Page 3 WARNINGS AND SAFETY NOTES Standard Battery Parameters Be very careful to choose the correct voltage for different types of battery otherwise you may cause damage to the batteries. Incorrect settings could cause the cells to fire or explode. Battery Fast Charge Nominal Cell Max.
-
Page 4: Specifications
WARNINGS AND SAFETY NOTES Discharging The main purpose of discharging is to clean the residual capacity of the battery, or to reduce the battery’ voltage to a defined level. The same attention should be paid to the discharging process as the charging process. The final discharge voltage should be set up correctly to avoid deep discharging. -
Page 5: Charger Layout
CHARGER LAYOUT COOLING FAN DISPLAY LED indicator LED indicator Channel 2 Channel 1 CHANNEL/SELECT Key START/ENTER Resume/Start the operation STOP Key INC (+) Key DEC (-) Key Balance Port Balance Port AC Input Power DC Input Power 100-240V 19-26V Charging connector - XT-60 Charging connector - XT-60 AC Input Cable included... -
Page 6: Program Flow Chart
PROGRAM FLOW CHART... - Page 7 CHARGE CURRENT SETTING It is important to consider the maximum allowed charging current of your battery before charging it. A charging current higher than the maximum allowable charging current may damage your battery and may cause a fire and explosion of the battery during charging. You must use the C-value indicated on the battery, which is the coefficient of the charge/ discharge of the battery.
-
Page 8: Operation
LITHIUM BATTERY (LiLo/LIPO/LIFE/LIHV) Lithium battery charging in balance mode This involves balancing the voltages between the different cells of the lithium battery. The charger monitors the internal voltage of each cell and limits the current of each cell to en- sure a balanced charge. - Page 9 OPERATION Press the STOP button to return to the last entry, press the ENTER button to enter the next menu. To select a charging program, press the ENTER button. Choose between balanced charging mode or Fast Charging mode. Press the ENTER button to enter the next screen. To return to the previous screen, press the STOP button.
-
Page 10: Cell Meter Test Program
CELL METER TEST PROGRAM This charger is equipped with a built-in high-speed micro- processor, it can be used as a cell tester and indicates the voltage of each cell, the total voltage of the battery pack and the highest / lowest voltage. Select the CELL METER program and press START Press the START button to display the highest / lowest voltage of each cell and the total battery voltage. -
Page 11: User Setting
USE STORED DATA This program recalls the data stored in the «SAVE DATA» function. To load the data, press the key START/ENTER once to make the data number field blink, select the number using the keys INC/DEC then press the START/ENTER for more than three seconds. - Page 12 USER SETTING Definition of a safety timer If a system failure fails to identify the capacity of an already full battery, this safety delay may prevent the battery from overcharging. The safety time should not be less than the full charge time of the battery, usually between 10 and 720 minutes.
-
Page 13: Warning And Error Messages
USER SETTING Firmware Update Press ENTER to update the firmware. Power distribution When using AC power, you can choose between intelligent or average distribution mode. WARNING AND ERROR MESSAGES In the event of an error, the charger will display a message and a beep sound. 1. - Page 14 If material defects or manufacturing faults should arise in a product distributed or manufactured by RC-Plus, a division of JSP Group Intl nv, and purchased by a consumer, we RC-Plus acknowledge the obligation to cor- rect those faults or defects within the limitations described below. This manufacturers warranty is in addition to, and does not affect, the legal or contractual rights of the consumer which arise from the purchase of such products.
- Page 15 This manual is protected by a copyright. Any publication, transmission or commercial use of this manual is prohibited without written permission. RC-PLUS and JSP Group Intl nv assumes no responsibility for printing errors in this manual. This manual is subject to technical changes.
- Page 16 CONFORMITY Declaration of Conformity RC-PLUS DUO POWER 100 AC/DC RC-PLUS, a division of JSP Group Intl nv declares under sole responsibility that the battery charger DUO POWER 100 AC/DC to which this declaration relate, conforms with the following CE-LVD standard;...
- Page 17 MEMO BATTERIES Write here your battery storage information [0] ------------------------------------------------------------------------------------------- [0] ------------------------------------------------------------------------------------------- [1] ------------------------------------------------------------------------------------------- [1] ------------------------------------------------------------------------------------------- [2] ------------------------------------------------------------------------------------------- [2] ------------------------------------------------------------------------------------------- [3] ------------------------------------------------------------------------------------------- [3] ------------------------------------------------------------------------------------------- [4] ------------------------------------------------------------------------------------------- [4] ------------------------------------------------------------------------------------------- [0] ------------------------------------------------------------------------------------------- [0] ------------------------------------------------------------------------------------------- [1] ------------------------------------------------------------------------------------------- [1] ------------------------------------------------------------------------------------------- [2] ------------------------------------------------------------------------------------------- [2] ------------------------------------------------------------------------------------------- [3] ------------------------------------------------------------------------------------------- [3] ------------------------------------------------------------------------------------------- [4] -------------------------------------------------------------------------------------------...
- Page 18 MEMO BATTERIES Write here your battery storage information [0] ------------------------------------------------------------------------------------------- [1] ------------------------------------------------------------------------------------------- [2] ------------------------------------------------------------------------------------------- [3] ------------------------------------------------------------------------------------------- [4] ------------------------------------------------------------------------------------------- [0] ------------------------------------------------------------------------------------------- [1] ------------------------------------------------------------------------------------------- [2] ------------------------------------------------------------------------------------------- [3] ------------------------------------------------------------------------------------------- [4] ------------------------------------------------------------------------------------------- [0] ------------------------------------------------------------------------------------------- [1] ------------------------------------------------------------------------------------------- [2] ------------------------------------------------------------------------------------------- [3] ------------------------------------------------------------------------------------------- [4] -------------------------------------------------------------------------------------------...
- Page 19 MEMO BATTERIES Write here your battery storage information [0] ------------------------------------------------------------------------------------------- [1] ------------------------------------------------------------------------------------------- [2] ------------------------------------------------------------------------------------------- [3] ------------------------------------------------------------------------------------------- [4] ------------------------------------------------------------------------------------------- [0] ------------------------------------------------------------------------------------------- [1] ------------------------------------------------------------------------------------------- [2] ------------------------------------------------------------------------------------------- [3] ------------------------------------------------------------------------------------------- [4] ------------------------------------------------------------------------------------------- [0] ------------------------------------------------------------------------------------------- [1] ------------------------------------------------------------------------------------------- [2] ------------------------------------------------------------------------------------------- [3] ------------------------------------------------------------------------------------------- [4] -------------------------------------------------------------------------------------------...
- Page 20 RC PLUS is a trademark licensed to JSP GROUP INTL nv Distributed in Europe by Pro Models Distribution Geelseweg 80 • 2250 Olen • Belgium • info@rcplus.eu #RC-CHA-213-EN 413911 247054...
