Appendix D: Technical Data
D Technical Data
D.1 Hardware Specifications
Order code
Color
Wired interface type
Connector
Antenna
Maximum range
Operating temperature
Storage temperature
Humidity
Vibration
Dimensions
Weight
Housing material
Protection class
Mounting
Power supply
Power consumption
® ™
Anybus Wireless Bolt User Manual
AWB2000
Black
Ethernet
Included plug connector
Internal dual-band 2.4 GHz and 5 GHz antenna
100 m (WLAN and Bluetooth)
Shadow: -40 to +65 °C
Direct sunlight: -40 to +45 °C
-40 to +85 °C
EN 600068-2-78: Damp heat, +40°C, 93% humidity for 4 days.
See datasheet
Height: 75 mm (95 mm incl. connector, 41 mm outside)
Diameter: 68 mm
81 g
Plastic (see datasheet for details)
Top (outside of host): IP66 / IP67 / UL NEMA 4X
Base (inside of host): IP21
M50 screw and nut (50.5 mm hole needed)
9–30 VDC (-5 % +20 %)
Cranking 12 V (ISO 7637-2:2011 pulse 4)
Reverse polarity protection
0.7 W idle, 1.7 W max.
AWB2001
White top and black base
Shadow: -40 to +65 °C
Direct sunlight: -40 to +65 °C
