HMS Networks Intesis INKNXUNI001I000 Installation Manual

Interface INKNXUNI001I000

Safety instructions

WARNING
Follow carefully this safety and installation instructions. Improper work may lead to serious harmful for your health and also
may damage seriously the interface.
• This interface must be installed by accredited technical personnel (electrician, KNX installer, or authorized technical
personnel) and following all the safety instructions given here and in accordance always with the country legislation for
installation of electric equipment.
• Disconnect always from the mains electricity supply any wires from the KNX bus, the AC indoor unit and the external
power supply before manipulating and connecting them to the interface.

Device description

Installation instructions

1. Check the IR Universal Controller device location using your Air Conditioner IR remote controller.
Make sure that you can control the AC unit properly with the IR remote controller in that location.
The IR Universal Controller can be installed on a wall mounted position or in a desktop position.
A
IMPORTANT: Keep in mind that some furniture and materials (carpets, curtains, glass, metal...) may effect on the IR
communication.
2. Connect the KNX bus cable to the KNX Connector inside the IR Universal device.
3. Power the KNX bus.
NOTE: Once installation is done, follow the instructions on user's manual for configuring and commissioning the
interface. You can find the user's manual and ETS' database using the next link:
https://www.intesis.com/products/ac-interfaces/knx-gateways/universal-knx-ir-is-ir-knx-1
Doc.Rev.1.1
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
Installation Manual
KNX button KNX cable
Binary
Inputs
B
