Configuration
4.2.2 Easy Config
Fig. 7 Easy Config page
To activate an Easy Config mode, select it from the dropdown menu and click on Set. The mode
will be activated immediately.
Easy Config Modes
EC
Role
1 Bluetooth PANU
–
2
–
3
4
Client
5 WLAN AP
6
Bluetooth NAP
7 WLAN AP
8 Bluetooth NAP
9
Bluetooth PANU
(any)
10
(any)
11
® ™
Anybus Wireless Bolt User Manual
Description
Configure as Bluetooth client and scan for another client (PANU–PANU).
Reset configuration to factory defaults.
Reset IP settings to factory defaults.
Wait for automatic configuration.
Configure units in mode 4 as clients.
Configure units in mode 4 as clients.
Restart as access point and connect clients.
Restart as access point and connect clients.
Apply PROFINET optimization to all units.
Configure as Bluetooth client and scan for another client (PANU–PANU).
Apply PROFINET optimization to both units.
Apply PROFINET optimization and restart.
Enable PROFIsafe mode.
