Summary of Contents for CYP CH-507TXWPUS
- Page 1 CH-507TXWPUS & RXWPUS HDMI over CAT5e/6/7 Wall-Plate Extender with IR/ RS232/LAN/PoE Operation Manual Operation Manual...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 5: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Hardware Description ......3 6.1 Transmitter .........3 6.2 Receiver ..........4 6.3 RS-232 Pin Definitions ......5 7. Connection Diagram ......6 8. -
Page 6: Introduction
1. INTRODUCTION The HDMI over CAT5e/6/7 Wall-Plate Extender can transmit and receive uncompressed audio/video over a single run of CAT5e/6/7 cable up to 100m with PoE, IR, RS232 and LAN. of a data transmission rate of 100Mbps. A True HDBaseT 5Play solution to make your home or office more efficient and easy with control. -
Page 7: Features
5. FEATURES • HDMI with 3D, 4Kx2K supported, HDCP and DVI compliant • Supports HDCP repeater and CEC bypass • Simultaneous transmission of uncompressed data over a single CAT5e/6/7 cable up to 100m/328ft • HDBaseT 5Play convergence: uncompressed high definition Video and Audio, LAN serving, Power over Ethernet and RS232/IR Controls •... -
Page 8: Hardware Description
6. HARDWARE DESCRIPTION The following sections describe the hardware components of the unit. 6.1 Transmitter RS-232 IN DC 24V POWER LINK IR 2 IR 1 HDMI IN Extender Blaster RS-232 IN: This slot is connect with D-Sub 9-pin cable from PC/ Laptop device RS-232 commands sending. -
Page 9: Receiver
POWER LED: This LED will illuminate when the device is connected to a power supply. LINK LED: This LED will illuminate when the both CAT5e/6/7 input and output signal is connected. IR 2 Extender: This slot is to connect with the IR Receiver cable included in the package for IR signal receiving. -
Page 10: Rs-232 Pin Definitions
(including internet access if available) to be shared between the transmitter and all connected receivers. Connect any Ethernet equipped device e.g. a Smart TV or games console to the LAN port of a receiver for that device to share the network/internet access. -
Page 11: Connection Diagram
7. CONNECTION DIAGRAM RS-232 Equipped PC Internet Modem or or Notebook Router CAT5e/6 RS-232 1.5m Power 60° Supply IR Blaster DVD or Blu-ray RS-232 IN Player DC 24V POWER LINK IR 2 IR 1 HDMI IN Extender Blaster 60° Notebook IR Extender RS-232 OUT POWER... -
Page 12: Specifications
8. SPECIFICATIONS Video Frequency 300MHz/9Gbps Transmitter Input Ports 1 x HDMI, 1 x IR Extender, 1 x LAN, 1 x RS232 Output Ports 1 x IR Blaster, 1 x CAT5e/6/7 Receiver Input Ports 1 x IR Extender, 1 x CAT5e/6/7 Output Ports 1 x HDMI, 1 x IR Blaster, 1 x LAN, 1 x RS232 CAT5e/6/7 Cable... -
Page 13: Cat5E/6/7 Cable Specification
8.1 CAT5e/6/7 Cable Specification Cable Range Pixel clock Video Data Supported Video Type rate Rate CAT5e/6/7 100 m <=225 MHz <=5.3 Gbps Up to 1080p, 60 Hz, 36 bits, 3D (data rates (HD Video) lower than 5.3 Gbps or below 225 MHz TMDS clock). - Page 16 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw MPM-507TXRXWPUS...
