Introduction

Before using the Handyscope HS6 DIFF first read chapter
Many technicians investigate electrical signals. Though the measurement may not
be electrical, the physical variable is often converted to an electrical signal, with
a special transducer. Common transducers are accelerometers, pressure probes,
current clamps and temperature probes. The advantages of converting the phys-
ical parameters to electrical signals are large, since many instruments for examin-
ing electrical signals are available.
The Handyscope HS6 DIFF is a portable four channel measuring instrument with
differential inputs. It is available in several models with different maximum sam-
pling rates. The native resolutions are 8, 12 and 14 bits and a user selectable res-
olution of 16 bits is available too, with adjusted maximum sampling rates:
Measuring
Resolution Channels
1 ch
8 bit 2 ch
3 or 4 ch
1 ch
12 bit 2 ch
3 or 4 ch
14 bit
16 bit
The Handyscope HS6 DIFF is available with two memory configurations, these are:
Measuring
Resolution Channels
1 ch
8 bit 2 ch
3 or 4 ch
1 ch
12, 14, 16 bit 2 ch
3 or 4 ch
Table 3.2: Maximum record lengths per channel
The Handyscope HS6 DIFF supports high speed continuous streaming measure-
ments. The maximum streaming rates when connected to a USB 3.0 port are:
HS6D-1000 HS6D-500
1 GSa/s 500 MSa/s
500 MSa/s 200 MSa/s
200 MSa/s 100 MSa/s
500 MSa/s 200 MSa/s
200 MSa/s 100 MSa/s
100 MSa/s 50 MSa/s
100 MSa/s 50 MSa/s
6.25 MSa/s 3.125 MSa/s
Table 3.1: Maximum sampling rates
Model
Standard with XM option
1 MSa 256 MSa
512 KSa 128 MSa
256 KSa 64 MSa
512 KSa 128 MSa
256 KSa 64 MSa
128 KSa 32 MSa
1 about safety.
Model
HS6D-200 HS6D-100
200 MSa/s 100 MSa/s
100 MSa/s 50 MSa/s
50 MSa/s 20 MSa/s
100 MSa/s 50 MSa/s
50 MSa/s 20 MSa/s
20 MSa/s 10 MSa/s
20 MSa/s 10 MSa/s
1.25 MSa/s 625 kSa/s
Introduction
3
HS6D-50
50 MSa/s
20 MSa/s
10 MSa/s
20 MSa/s
10 MSa/s
5 MSa/s
5 MSa/s
312.5 kSa/s
