Front panel
7.1
Channel input connectors
The CH1 – CH4 BNC connectors are the main inputs of the acquisition system. The
isolated BNC connectors are not connected to the ground of the Handyscope HS6
DIFF.
7.2
Power indicator
A power indicator is situated at the top cover of the instrument. It is lit when the
Handyscope HS6 DIFF is powered.
Figure 7.1: Front panel
7
27
Front panel
