Specifications
To achieve rated accuracy, allow the instrument to settle for 20 minutes. When
subjected to extreme temperatures, allow additional time for internal tempera-
tures to stabilize. Because of temperature compensated calibration, the Handy-
scope HS6 DIFF will settle within specified accuracy regardless of the surrounding
temperature.
9.1

Acquisition system

Number of input channels
CH1, CH2, CH3, CH4
Type
Resolution
Accuracy
Ranges (full scale)
Coupling
Impedance
SafeGround disabled
SafeGround enabled
Maximum voltage
Maximum Common Mode voltage 200 mV to 800 mV ranges : 2 V
Common Mode Rejection Ratio
Bandwidth
-3 dB, at 75 % of full scale
Limit, selectable per channel
AC coupling cut off freq. (-3dB)
SureConnect
Maximum voltage on connection 200 V (DC + AC peak <10 kHz)
Resistance measurement
Ranges
Accuracy
Response time (to 95%)
SafeGround
Maximum voltage on connection 200 V (DC + AC peak <10 kHz)
Maximum switch off current
Response time
4 analog
Isolated BNC
Differential input
8, 12, 14, 16 bit user selectable
0.25% of full scale ± 1 LSB
±200 mV ±400 mV
±2 V ±4 V
±20 V ±40 V
AC/DC
2 MΩ / 12 pF ± 1 %
1 MΩ / 20 pF ± 1 %
200 V (DC + AC peak <10 kHz)
2 V to 8 V ranges : 20 V
20 V to 80 V ranges : 200 V
-47 dB
HS6D-1000 HS6D-500 HS6D-200
250 MHz 250 MHz 250 MHz
Off (250 MHz) Off (250 MHz) Off (250 MHz)
150 MHz 150 MHz 150 MHz
100 MHz 100 MHz 100 MHz
75 MHz 75 MHz 75 MHz
±1.5 Hz
Optionally available (option S)
Optionally available (option S)
100 Ohm to 2 MOhm full scale
1%
<10 µs
Optionally available (option G)
500 mA
<100 ns
9
±800 mV
±8 V
±80 V
HS6D-100 HS6D-50
100 MHz 100 MHz
Off (100 MHz) Off (100 MHz)
75 MHz 75 MHz
50 MHz 50 MHz
25 MHz 25 MHz
