Introduction

Before using the Handyscope HS3 first read chapter
safety.
Many technicians investigate electrical signals. Though the
measurement may not be electrical, the physical variable is of-
ten converted to an electrical signal, with a special transducer.
Common transducers are accelerometers, pressure probes, current
clamps and temperature probes. The advantages of converting the
physical parameters to electrical signals are large, since many in-
struments for examining electrical signals are available.
The Handyscope HS3 is a portable two channel measuring in-
strument with Arbitrary Waveform Generator. The Handyscope
HS3 is available in several models with different maximum sam-
pling frequencies: 5 MS/s, 10 MS/s, 25 MS/s, 50 MS/s or 100
MS/s. The native resolution is 12 bits, but user selectable resolu-
tions of 8, 14 and 16 bits are available too, with adjusted maximum
sampling frequency:
resolution
8 bit
12 bit
14 bit
16 bit
Table 3.1: Maximum sampling frequencies
With the accompanying software the Handyscope HS3 can be
used as an oscilloscope, a spectrum analyzer, a true RMS voltmeter
or a transient recorder. All instruments measure by sampling the
input signals, digitizing the values, process them, save them and
display them.
Maximum sampling frequency
100 MS/s
5, 10, 25 or 50 MS/s, depending on model
3.125 MS/s
195 kS/s
3
1 about
5
Introduction
