9.7

Physical

Height
Length
Width
Weight
USB cord length
9.8

I/O connectors

CH1, CH2, CH3, CH4
USB
Extension connector
Power
CMI connectors 1–2
9.9

Interface

Interface
9.10

System requirements

PC I/O connection
Operating System
9.11

Environmental conditions

Operating
Ambient temperature
Relative humidity
Storage
Ambient temperature
Relative humidity
36
Chapter 9
25 mm / 1.0"
170 mm / 6.7"
140 mm / 5.2"
500 g / 17 ounce
1.8 m / 70"
Isolated BNC
Fixed cable with USB 3.0 type A plug, 1.8 m
D-sub 9 pins female
3.5 mm power socket
HDMI type C socket
USB 3.0 SuperSpeed (5 Gbit/s)
(USB 2.0 HighSpeed (480 Mbit/s) compatible)
USB 2.0, USB 3.0 or USB 3.1
Windows 10, 32 and 64 bits
◦ ◦ ◦
20 C to 25 C (10 C to 40
10 to 90% non condensing
◦ ◦
-20 C to 70 C
5 to 95% non condensing
◦
C without specifications)
