Introduction

Before using the Handyscope HS5 first read chapter
Many technicians investigate electrical signals. Though the measurement may not
be electrical, the physical variable is often converted to an electrical signal, with a
special transducer. Common transducers are accelerometers, pressure probes,
current clamps and temperature probes. The advantages of converting the phys-
ical parameters to electrical signals are large, since many instruments for examin-
ing electrical signals are available.
The Handyscope HS5 is a portable two channel measuring instrument with Arbi-
trary Waveform Generator. The Handyscope HS5 is available in several models
with different maximum sampling frequencies: 50 MS/s, 100 MS/s, 200 MS/s or
500 MS/s. The native resolutions are 8, 12 and 14 bits and a user selectable res-
olution of 16 bits is available too, with adjusted maximum sampling frequencies:
Handyscope HS5
Model 540
Model 530
Model 220
Model 110
Model 055
Table 3.1: Maximum sampling frequencies
The Handyscope HS5 supports high speed continuous streaming measurements.
The maximum streaming rates are:
Channels
8 / 12 bit
CH1 500 MS/s
CH1+CH2 200 MS/s
CH1 500 MS/s
CH1+CH2 200 MS/s
CH1 200 MS/s
CH1+CH2 100 MS/s
CH1 100 MS/s
CH1+CH2 50 MS/s
CH1 50 MS/s
CH1+CH2 20 MS/s
1 about safety.
Resolution
14 bit 16 bit
100 MS/s 6.25 MS/s
100 MS/s 6.25 MS/s
50 MS/s 3.125 MS/s
20 MS/s 1.25 MS/s
10 MS/s 625 kS/s
Introduction
