Installation
1
0 . 3 2
( 8 m
Position the strike plate on the door frame aligning it with
the center of the lock's mounting holes
3
Drill 025" (635 mm) pilot holes using a 1/6" drill bit
5
0 . 3 2
( 8 m
Adjust the strike plate to the proper position (32" (8 mm)
from the door edge) then tighten the self tapping screws
i n
m )
Mark Here
Drill Pilot
Holes Here
i n
m )
2
0 . 3 2
( 8 m
Allow 32" (8 mm) from door edge and mark the position
of the adjustment slot holes
4
Position the strike plate and the self tapping screws into the
adjustment slot holes Do not tighten the screws
6
Position and tighten the remaining self tapping screw
into the center hole
i n
m )
Mark Here
11
