Next, verify the StorageSets you have configured:
SWXRC> SHOW STORAGESETS
The controller responds with a display similar to that shown below:
Name
STRIPE_MIRROR
STRIPE_SET_1
MIRROR_SET_1
MIRROR_SET_3
MIRROR_SET_4
RAID_SET_1
RAID_SET_2
SPARESET
FAILEDSET
JBOD devices are not displayed in this report. To display JBOD devices, enter the following:
SWXCR> SHOW DEVICES
Record the above information in the following table. In the event of a controller failure, the
information that is recorded here will assist you in reconstruction of the storageset on your
RAID Array 410.
EK–SMRA3–IG. C01
Chapter 2. Creating an Initial Configuration
StorageSet Uses
stripeset MIRROR_SET_3
MIRROR_SET_4
stripeset DISK110
DISK210
DISK310
mirrorset DISK120
DISK220
mirrorset DISK320
DISK420
mirrorset DISK520
DISK620
raidset DISK100
DISK200
DISK300
raidset DISK400
DISK500
DISK600
spareset DISK610
failedset
Used by
D500
D2
D400
STRIPE_MIRROR
STRIPE_MIRROR
D0
D1
