Getting Started – RAID Array 410 for HP-UX
1.2

Unpacking the SWXRA-Yx

The SWXRA-Yx RAID Array 410 is packed in a corrugated carton attached to a wooden
shipping pallet, as shown in Figure 1–2A. Unpack the SWXRA-Yx as follows:
1. Remove the shipping straps (Figure 1–2A).
2. Remove the top cover (Figure 1–2B).
3. Remove the ramp from the top of the shipping carton (Figure 1–2B) and set it aside for
subsequent use in moving the SWXRA-Yx off the pallet.
4. Remove the two foam cushions from the top of the SWXRA-Yx container (Figure 1–2B).
5. Remove the sealed cardboard box packed beside the subsystem unit. It contains cable and
documention.
6. Remove the cardboard carton surrounding the SWXRA-Yx(Figure 1–2B).
7. Remove the plastic barrier bag (Figure 1–2C).
8. Once the SWXRA-Yx is exposed (Figure 1–2D), examine the equipment for any apparent
damage. Report any such problems immediately to your sales representative.
Figure 1–2 Unpacking the SWXRA-Yx RAID Array 410
1–2
Before unpacking the equipment, inspect the shipping carton for
signs of external damage. Report any damage to the local carrier
and to your sales representative.
NOTE
EK–SMRA3–IG. C01
