Front Runner Slimline II Manual

Toyota tacoma 2005 onwards bed rack load bar kit

Hide thumbs Also See for Slimline II:

READ ME FIRST:

Thank you for purchasing a Front Runner Slimline II Load Bed Rack or Load Bar Kit.

Your Kit will contain the following items:

1.) A Slimline II Tray or Load Bar set

2.) Universal Load Bed Legs

3.) Bed Rail Nut Kit

This document will help you fit the Slimeline II Tray or Load Bars to your specific vehicle. If you are mounting

a Slimline II Tray, Please continue with Section 1. If you are fitting Load Bars, please refer to Section 2.

installation of slimline ii tray

Note: When assembling the Legs, discard the Fittings Instructions received with the Legs (Document

LASS026) and assemble the Legs as per Assembly Instructions received with your Nut Kit (RRAC901). Not

all the components received with the Legs will be used as they will be replaced by the Nut Kit.

If your Slimline II Tray is not already assembled, assemble it as per the Slimline II Tray Universal

Assembly Instruction (Document RRSTUNI).

(

)

Remove End Cap and Slide two

Leg Assemblies into each Rail

REV_A00

Toyota TACOMA

2005 Onwards

BED RACK LOAD BAR KIT

KRTT900T / KRTT901T

INSTALL TIME: 15 mins

Table of Contents

Do you have a question about the Slimline II and is the answer not in the manual?

Page 1 This document will help you fit the Slimeline II Tray or Load Bars to your specific vehicle. If you are mounting a Slimline II Tray, Please continue with Section 1. If you are fitting Load Bars, please refer to Section 2.
Page 2 Adjust the two leg assemblies either side of the Midpoint of the factory rails so that they are 884 mm apart - outside to outside as shown below. ( C ) With your Rack in the upside down position ( Product...
Page 3 INSTALL TIME: 15 mins installation OF LOAD BARS Note: When assembling the Legs, discard the Fittings Instructions received with the Legs (Document LASS026) and assemble the Legs as per Assembly Instructions received with your Nut Kit (RRAC901). Not all the components received with the Legs will be used as they will be replaced by the Nut Kit. Remove End Cap and Slide two Leg Assemblies into each Rail Slide two M8 x 25 Hex Bolts supplied with the Universal Load...
