8. Adhere the top and bottom Wheels (11) & (12) to the Glass Door (06). The upper wheels have an adjustable bolt and lock nut that can alter the door level
as necessary. The lower wheel features a press that works to secure the wheel to the bottom Guide Rail (02).
NOTE: When installed, the upper wheel lock nut and lower wheel press button should be pointing upwards.
Refer to Figure 10 for details.
9. Position the top door wheels into the top Guide Rail (02) using a sliding motion. Adjoin the bottom wheels and the Guide Rail by pushing the bottom
wheels into the bottom rail and pressing down the button located on the Wheel Assembly.
NOTE: DO NOT use a power screwdriver for adjustments. Adjust the upper wheels using the Phillips screwdriver until they glide smoothly, and the door
tightly closes.
