Specifications - Edgetech 701 DIGITAL LINK User Hardware Manual

2-2

2.0 SPECIFICATIONS

With 2U-SKB Case:
15.75 cm (6.20 in.) high
56.90 cm (22.40 in.) wide.
60.96 cm (24 in.) wide
Size
Without Case:
8.3 cm (3.25 in.) high
48.3 cm (19 in.) wide
43.2 cm (17 in.) deep
With 2u-SKB Case:
10.80 kg (23.8 lb.)
Weight
Without Case:
6.4 kg (14 lb.)
Case construction Aluminum 19-inch rack mount
Shipping Container Carton
Type
61 cm (24 in.) high
Shipping Container Size 61 cm (24 in.) wide
30.5 cm (12 in.) deep
Shipping Weight 11.3 Kg (25 lb.)
Operating Temp. 0–45°C (32–113°F)
Storage Temp. -10-60⁰C (14-140⁰F)
Operating relative 5–90% (non-condensing)
humidity
5-90%
Non-operating storage
relative humidity
100-264 VAC, 50/60 Hz, auto-switching
Input voltage
Input power ~ 120W
Power to Towfish 400 VDC
Processor
Memory
Data storage
Display
701 Digital Link
701-DL DIGITAL LINK (IN 2U-SKB CASE)
—
—
—
—
RACK MOUNT (701-DL AND 2U
COMPUTER IN 6U CASE)
17.8 cm (7 in.) high
43.2 cm (17 in.) wide
45.7 cm (19 in.) deep
19.5 kg (43 lb.)
Aluminum 19-inch rack mount
Sealed high impact polyurethane case
71.1 cm (28 in.) high
66.0 cm (26 in.) wide
50.8 cm (20 in.) deep
47.7 kg (105 lb.)
0–45°C (32–113°F)
-10-60⁰C (14-140⁰F)
5–90% (non-condensing)
5-90%
100-264 VAC, 50/60 Hz, auto-switching
~ 120 W
400 VDC
Intel Core, I7, 3.6 GHz Quad-Core
4 GB, 1333 MHz
DVD/RW drive
1-TB hard drive (data)
500-GB hard drive (OS)
23.6-inch LCD monitor
0004809_REV_F
