Quick Start Guide
MX150
IN THIS GUIDE

Step 1: Begin | 1

Step 1: Begin
IN THIS SECTION
To mount and connect power to the Juniper Networks
Electrostatic discharge (ESD) grounding strap (not provided)
One pair of front-mounting bracket (provided)
Eight screws to secure the mounting bracket (provided)
Four screws to secure the chassis and mounting bracket to the rack (not provided)
Screwdriver appropriate for your rack mounting screws (not provided)
An AC power cord with plugs appropriate for your geographical location (provided)
RJ-45 cable and RJ-45 to DB-9 serial port adapter (provided)
®
MX150, and perform initial configuration, you need:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX150 and is the answer not in the manual?

Questions and answers

Related Manuals for Juniper MX150

Summary of Contents for Juniper MX150

  • Page 1 Mount the MX150 | 2 Connect Power to the Switch | 3 ® To mount and connect power to the Juniper Networks MX150, and perform initial configuration, you need: Electrostatic discharge (ESD) grounding strap (not provided) One pair of front-mounting bracket (provided)
  • Page 2 Mount the MX150 You can mount the MX150 device on two posts of a 19-in. rack by using the mounting brackets provided with the device. The device weighs approximately 9.4 lb (4.3 kg). Two persons are required for mounting the device.
  • Page 3 AC power outlet by using the power cord. The MX150 device uses a fixed, internal AC power supply. 2. Set the power switch to the off (O) position.
  • Page 4 login: root 2. Start the CLI: root% cli 3. Enter configuration mode: root> configure 4. Remove Zero Touch Provisioning (ZTP) which enables the device to automatically upgrade the Junos OS software and auto-install configuration files from the network. root# delete chassis auto-image-upgrade 5.
  • Page 5 Power Cable Warning (Japanese) | 6 Contacting Juniper Networks | 6 See the complete MX Series documentation at https://www.juniper.net/documentation/product/en_US/mx150. Safety Warnings Summary This is a summary of safety warnings. For a complete list of warnings, including translations, see the MX Series...
  • Page 6 Before connecting the device to a power source, read the installation instructions in the MX150 documentation. The MX150 device weighs approximately 9.4 lb (4.3 kg). Manually installing the device in a rack at a height above 60 in. (152.4 cm) requires two persons; one to lift the device and the second to install the mounting screws. To prevent injury while lifting, keep your back straight and lift with your legs, not your back.
  • Page 7 Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners. Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice.
