Mindray DC-8 EXP Operator's Manual page 43

Setting Default Item
You can set a measurement, calculation or study in the [Selected Items] as the default item. The
default item will be activated automatically while entering the measurement menu containing it.
1. Select an item from the [Menu] list.
2. Click [Default], and the defaulted item is marked with a √ .
To deselect the default tool, select it and click [Default] or set another item as default.
If a certain study is set to the default item, it displays the submenu of the study
Tips:
automatically when entering this measurement menu.
Adjusting Item Position
You can adjust the position of the measurement, calculation or study in the [Selected Items] list.
1. Select an item in the [Selected Items].
2. Click [Up]/ [Down].
The order in the list is also the item position in the menu.
2.4.2.4 User-defined Measurement/Calculation/Study
Please guarantee the correctness and validity of the formula defined, otherwise Mindray
NOTE:
will not be liable for damage caused by improper definition of the formula.
User-defined Measurement
1. Enter [Measure Preset] -> [Measure] page.
2. Click [New].
The "Measurement Custom Wizard" dialog box pops up, as shown in the following figure.
3. Input Name in the "Measurement Custom Wizard" dialog box, and click [Next].
4. Select the [Tool Type], [App Region] and the Measure Result.
Measure Preset 2-17
