Keys
Clear
Report
Cursor
Trackball
Multifunctional
knob(Nav.)
For details on key functions, see "System Overview" in the Operator's Manual [Basic Volume].
1.2

Measurement Menu

Menus of General and Application measurement are different. For more information on
measurement menu, refer to "3 General Measurement" and the specified application measurement
chapter.
Measurement menu and the corresponding touch screen are as follows:
1-2 Overview
Short press: to return to the previous measurement step, or delete the
caliper backwards.
Long press: to clear all measurement calipers on the screen and data in the
result window.
To enter/ exit the report page.
To show the cursor.
Move the cursor.
To enable the commonly used measure function or used for selecting
measurement item by rotating.
Basic Operations
Menu title
Location
Tools (main menu)
Menu title (submenu)
Tools (submenu)
