2. Use the Distance method in 2D General Measurements to measure UT L and Cervix L. The
system calculates UT-L/CX-L.
8.4.3

Study Tool Operations

Uterus
Function: measures UT L, UT H, UT W and Endo, calculates UT Vol, Uterine Body and UT-L/CX-L.
1. Select [Uterus] in the measurement menu.
2. Use the Distance method in 2D General Measurements to measure UT L, UT H, UT W and
Endo.
UT Vol and Uterus Sum are calculated automatically.
If Cervix L has been measured, the system also calculates UT-L/CX-L.
Uterine Cervix
Function: measures Cervix L, Cervix H and Cervix W, calculates UT-L/CX-L.
1. Select [Uterine Cervix] in the measurement menu.
2. Use the Distance method in 2D General Measurements to measure Cervix L, Cervix H and
Cervix W.
Ovary
Function: measures Ovary L, Ovary H and Ovary W, calculates Ovary Vol.
NOTE: Need to be measured in left and right side respectively.
1. Select [Ovary] in the measurement menu.
2. Use the Distance method in 2D General Measurements to measure Ovary L, Ovary H and
Ovary W. The Ovary Vol is calculated automatically.
Follicle
Function: Measures the length, width and height of follicle using method Distance and calculates
the average of length, width and height as well as the follicle volume.
Results
Average Diameter
Follicle Volume
Up to 16 follicles can be measured. Specify the serial numbers of the follicles before measuring a
follicle.
NOTE: Need to be measured in left and right side respectively.
Takes Follicle1 as an example. Measurements of other items are similar.
1. Select [Follicle1] in the measurement menu.
8-4 Gynecology
Method
2-distance
Average
3-distance
Average
1-distance Vol ＝
2-distance
Vol ＝
3-distance
Vol ＝
Formulae
(
Length +
Width
Diam ＝
(
+
Length Width
Diam ＝
π
( )
3
Length
6
π
( )
×
2
Length Width
6
π
× ×
length Width Height
6
)
2
)
+
Height
3
