- Page 1 Focus & Zoom Controller SRH-3 & SRH-360 Installation Guide Date 20.02 2020...
- Page 2 In no event shall ARRI or its subsidiaries be liable for or have a remedy for recovery of any special, direct, indirect, incidental, or consequential damages, including, but not limited to lost profits, lost...
- Page 3 Table of Contents Table of Contents 1 For your safety 2 Installation 3 Assigning the Controllers...
- Page 4 For your safety For your safety Warning The SRH-3 system and products should only be used by experienced and trained operators. This product is NOT designed for inexperienced users and should not and must not be used without proper training.
- Page 5 Installation Installing the Controllers CAUTION Disconnect any power supply from the remote panel. 2.1 Preparation NOTE Unscrew and remove the joystick handle first. 2.2 Dismantling the covers Torx screws NOTE A T10 Torx screwdriver is needed for the next steps. Covers Remove the 4 screws from each cover on the left side of the remote control, and then remove both...
- Page 6 Installation This means that the modules cannot be installed incorrectly. Place the Focus Wheel at the upper position. Place the four Torx screws and tighten them. 2.6 Connecting and mounting the zoom controller Connect the bus cable to any of the two four pin ports of the Focus Wheel board.
- Page 7 Controller Assignment 2.8 Attaching the bottom cover Torx screws Turn the panels over and place the bottom cover on the housing. Place the Torx screws and tighten the screws evenly. Assigning the new controllers 3.1Changing into the FIZ menu The FIZ home screen can be reached by Selecting FIZ in the Home Screen.
