- Page 1 4x4 HDMI & Full 3D support over CAT5 Matrix with IR Pass-through To avoid EMI issue, complete STP Cat6 cable is strongly recommended! P/N: AV-GM0783-S1...
-
Page 2: Table Of Contents
However, like all electronic equipments, the AV-GM0783-S1 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
INTRODUCTION The AV-GM0783-S1 4x4 HDMI & Full 3D support over CAT5 Matrix with IR Pass-through provides the most flexible and cost effective solution in the market to route high definition video sources plus multi-channel (up to 7.1-channel) digital audio from any of the four HDMI sources to the remote displays at the same time. -
Page 4: Specifications
SPECIFICATIONS Model Name AV-GM0783-S1 Technical MA-5144 MA-5144RX True 4x4 matrix switcher Role of usage Receiver [RX] Transmitter [TX] HDMI compliance HDMI Deep Color & full 3D HDCP compliance Video bandwidth Single-link 225MHz [6.75Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 36-bit color Audio support Surround sound (up to 7.1ch) or stereo digital audio... - Page 5 [IR Main] IR control on all source [IR] Receives IR commands from devices remote control [IR1~IR4] IR control on individual source device DIP switch [SW1~SW4] 2-pin for EDID and audio setting modes [MA-5144 only] [SW Main] 4-pin operation mode & firmware update Mechanical MA-5144 MA-5144RX...
-
Page 6: Package Contents
* Additional IR remote controllers and IR blasters can be purchased as optional accessories to control the HDMI sources located separately. PANEL DESCRIPTIONS Transmitting unit ► AV-GM0783-S1-TX Front Panel Port 1-4 Select: Push-in button for selecting input channel Port 1-4: Input source channels mapping LED for each output channel... -
Page 7: Receiving Unit
IR 1-4: IR extender jacks for individual HDMI source control with IR blasters OUT 1-4: RJ-45 TMDS/DDC outputs for each output channel IR Main: IR extender jack for all HDMI source control [default socket for IR blaster] Receiving unit ► AV-GM0783-S1-RX Front Panel Rear Panel... - Page 8 INPUT SELECT: Push button for switching input source channel in sequential order Signal Level 0-7: Adjust the 8-level equalization control to the received HDMI signals. The HDMI signal level varies from 0 (strongest) to 7 (weakest) for respective transmission length from longest possible range to short distance.
-
Page 9: Dip Switch
DIP SWITCH SW1-SW4 for EDID/Audio DIP Switch Position Video Audio Description Pin#1 Pin#2 Default Mode 1 – EDID up to 1080p video & surround sound Up to 1080p Surround OFF [ ] OFF [ ] audio output up to 7.1ch (DTS-HD Master & Dolby TrueHD) Default Mode 2 –... - Page 10 SW MAIN for firmware update (for technical support only) DIP Switch Position Pin#1 Pin#2 Pin#3 Pin#4 ON [ ] Normal Operation Mode OFF [ ] OFF [ ] OFF [ ] ON [ ] ON [ ] Firmware Update Mode OFF [ ] OFF [ ] Note...
-
Page 11: Ir Pass-Through
IR PASS-THROUGH IR Extenders IR Blaster IR Receiver IR Sockets MA-5144 IR Main: The default location for IR blaster to transmit all IR command signals received from any of the four remote receivers to all of the HDMI sources. IR PASS-THROUGH 1-4: IR blaster connected here can only transmit IR command signals from the remote receivers that are setting at respective input channel from 1 to 4. -
Page 12: Hardware Installation
You can buy any IR extension cables in the market that are compatible to the definition of the IR sockets for the matrix if necessary for replacement use. However, IR cables longer than 2m (6-ft) may not work. HARDWARE INSTALLATION MA-5144 as master 1. -
Page 13: Connection Diagram
CONNECTION DIAGRAM... -
Page 14: Operation And Ir Control
OPERATION AND IR CONTROL Source Side Method A: Push-in Button Push the red switch button on output port to select which port to be changed. Method B: IR Remote Control Choose the output port you want to make channel switch from OUT1 to OUT4 then press 1-4 channel button to choose the HDMI input source shown on the chosen output display. - Page 15 Channel Control Method C: Software Control through RS-232 port HDMI Input Source Selection Mapping Area HDMI Output Port Selection Mapping Area Status Indicator Software Control Menu 1. Setting button: Click Get button to read back device ID. Click Set button to write device ID. Click Rename button to open the String Table.
- Page 16 etc.
- Page 17 Click Save String Table to save the caption setting (turn effective after program restart). Click Set Default to pop up the confirmation message below to erase the captions and reset the string table back to default setting (turn effective after program restart). 2.
- Page 18 5. Mapping button: Select All Output elect “set all output”, and then select the source on main menu. You can quickly set all output to the same source. Unselect All Output Release output selection. Select Input1~4-Output Select Input Source. Then select the output port icon. For example Select input source 1.
- Page 19 Click Fast select button. Quick setting. Input one > Output Port one Input two > Output Port two ….. Click Fast select pull down menu. Select Input Num-Output Num Input source #1 > Output port #1 Input source #2 > Output port #2 …..
- Page 20 Pull down menu and select which source to be sent to this output port. One by one setting On main menu screen First select input source. Then select the output ports which you want to send the video and audio from this source. When you select the input source, the source will change to gray.
-
Page 21: Display Side
Output C selects Input 1 Output G selects Input 1 Output C selects Input 2 Output G selects Input 2 Output C selects Input 3 Output G selects Input 3 Output C selects Input 4 Output G selects Input 4 Output C selects Input 5 Output G selects Input 5 Output C selects Input 6... - Page 22 in a couple of seconds. Switch input port in descending order* Switch input port in ascending order* Switch the display channel at the SOURCE SEL. 1 remote site to input port 1 Switch the display channel at the SOURCE SEL. 2 remote site to input port 2 Switch the display channel at the SOURCE SEL.
-
Page 23: Edid Learning
EDID LEARNING The EDID learning function is only necessary whenever you encounter any display on the HDMI output port that cannot play audio and video properly. Because the HDMI source devices and displays may have various level of capability in playing audio and video, the general principle is that the source device will output the lowest standards in audio format and video resolutions to be commonly acceptable among all HDMI displays. -
Page 24: Ir Discrete Code
IR DISCRETE CODE Default Custom Code IR2 Code: 00 FF Function POWER 0x17 0x02 0x0A 0x0C SOURCE SEL. 1 SOURCE SEL. 2 SOURCE SEL. 3 SOURCE SEL. 4 0x54 0x55 0x56 0x01 0x57 0x58 0x59 0x06 Output Port 1 Input 1 - 0x18 Input 2 - 0x5B Input 3 - 0x19 Input 4 - 0x07... - Page 25 Custom Code - IR4 Code: 0x13 0x31 Custom Code: 0x13 0x31 Output 1 Output 2 Output 3 Output 4 Source 1 0xAE 0xBE 0xCE 0xDE Source 2 0xAD 0xBD 0xCD 0xDD Source 3 0xAC 0xBC 0xCC 0xDC Source 4 0xAB 0xBB 0xCB 0xDB...
-
Page 26: Faq
The quality of output video is not good enough, how can I do? Please adjust the 8-level equalization on the receiver units. The HDMI signal level varies from 0 (strongest) to 7 (weakest) for respective transmission length from longest possible range to short distance. - Page 27 My TV can support 1080p, but why there is no audio? The default setting of this device is 1080p & 7.1ch audio, so there would be a problem if the TV cannot support 7.1ch audio. Please change the DIP switch of the chosen input from Default Mode to Safe Mode.
-
Page 28: Notice
NOTICE 1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to retrieve and provide DVI/HDMI EDID information. 2. All HDMI over CAT5 transmission distances are measured using Belden 1583A CAT5e 125MHz LAN cable and ASTRODESIGN Video Signal Generator VG-859C & VG-870B. 3. -
Page 29: Warranty
The SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the AV-GM0783-S1 features and specifications is subject to change without further notice.
