Platform-to-Codec
Table 2-1. J2 Connector Pinouts (Continued)
2-4
Pin Number
Signal
J2.32
DGND
J2.33
3.3V_A_DRV
J2.34
AGND
J2.35
3.3V_A_DRV
J2.36
AGND
J2.37
3.3V_A
J2.38
AGND
J2.39
3.3V_A
J2.40
AGND
Description
Digital ground
Output driver supply 3.3 V
Analog ground
Output driver supply 3.3 V
Analog ground
Analog 3.3 V
Analog ground
Analog 3.3 V
Analog ground
