DS125BR111EVM User's Guide
SMA Evaluation Kit
User's Guide
Literature Number: SNLU168A
August 2014 – Revised August 2014

Advertisement

loading
Need help?

Need help?

Do you have a question about the DS125BR111EVM and is the answer not in the manual?

Questions and answers

Summary of Contents for Texas Instruments DS125BR111EVM

  • Page 1 DS125BR111EVM User's Guide SMA Evaluation Kit User's Guide Literature Number: SNLU168A August 2014 – Revised August 2014...
  • Page 2 DS125BR111EVM User's Guide SMA Evaluation Kit The DS125BR111EVM – SMA evaluation kit provides a complete high bandwidth platform to evaluate the 10GbE, PCIe, and SAS/SATA signal conditioning features of the Texas Instruments DS125BR111 repeater/redriver. The DS125BR111EVM can be used for standard compliance testing, performance evaluation, and initial system prototyping.
  • Page 3 DS125BR111EVM Board Ordering Information Table 1. DS125BR111EVM Ordering Information DEVICE QUANTITY DS125BR111RTWR 1000 DS125BR111RTWT SMA Evaluation Kit: DS125BR111EVM SNLU168A – August 2014 – Revised August 2014 DS125BR111EVM User's Guide SMA Evaluation Kit Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 4 Figure 1. DS125BR111EVM Evaluation Board Setup The DS125BR111EVM – SMA evaluation kit can be used in three different modes: 1. Pin Control (provides access to selected signal integrity settings) 2. SMBus Mode (full access to signal integrity and control settings) 3.
  • Page 5 PIN HEADER CONNECTION Figure 2. 4-Level IO Control on EVM The DS125BR111EVM is quickly setup for use in pin control configuration. Jumpers listed below should be installed on the EVM for pin control. 1. J4 – 3.3 V operation: Use the J1 and J3 connectors to supply 3.3 V power to the EVM. The EVM power connections are designed to accommodate 1287-ST quick connect tabs or directly soldered to power leads for connection to a lab power supply.
  • Page 6 A serial EEPROM may also be used to configure one or more DS125BR111 devices. This configuration mode is accessed by setting the ENSMB 4-level input to FLOAT. For additional information please see the device datasheet. DS125BR111EVM User's Guide SMA Evaluation Kit SNLU168A – August 2014 – Revised August 2014 Submit Documentation Feedback...
  • Page 7 SAS-3 environments are EQ = Level 4, VOD_DB = 0 and VOD_SEL = 1 in Pin mode or EQ = 03'h, VOD = 111'b, and VOD_DB = 000'b in SMBus mode. SETUP1: PRBS7 Generator (no TX FIR) → 10" FR4 → DS125BR111EVM → Scope DS125BR111 Settings 1.
  • Page 8 Schematic www.ti.com Schematic Figure 4. DS125BR111EVM Schematic DS125BR111EVM User's Guide SMA Evaluation Kit SNLU168A – August 2014 – Revised August 2014 Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 9 Schematic www.ti.com Figure 5. DS125BR111EVM Schematic SNLU168A – August 2014 – Revised August 2014 DS125BR111EVM User's Guide SMA Evaluation Kit Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 10: Bill Of Materials

    SHUNT JUMPER .1" BLACK GOLD J38, J39, J40, J41 J1, J2, J3 1287-STK-ND 1287-ST Connector TAB 0.250 Solder R36, R38, R39 DS125BR111EVM User's Guide SMA Evaluation Kit SNLU168A – August 2014 – Revised August 2014 Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 11: Revision History

    Page ........................• Changed EVM Photo. NOTE: Page numbers for previous revisions may differ from page numbers in the current version. SNLU168A – August 2014 – Revised August 2014 Revision History Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
