DAB E SYBOX MINI Assembly And Dismantling Manual page 8

DISMANTLING
9
10
11
7
Pull off the o-ring in picture and
1
keep it separated from the rest:
2
due to its peculiar deformation
Unplug the connectors:
3
1-pressure sensor; 2-flow sen-
sor; 3-display flat cable
Unplug the power cable connec-
tor by first lifting the plastic tooth
highlighted in the picture
Remove the power cable, paying
attention to the positioning (requi-
red for a correct reassembly)
