- Page 1 ZK105L User Manual Document Title ZK105L User Manual Version N/A Author Bruce.Chen Date 2019‐04‐18 Status Release Document Control ID ...
- Page 2 ZK105L User Manual General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession. Furthermore, system validation of ...
- Page 3 The ZK105LSeries are a series of water resistant GPS tracker designed for Scooter. Their built-in GPS receiver has superior sensitivity and fast time to first fix (TTFF). Their LTEallows the ZK105L Series' location to be monitoredin real time or periodically tracked bya backend server or other specified terminals.
- Page 4 ZK105L User Manual 3.1.2 I nterface Definition The power cable input 36V, red wire for positive , black wire for negative 4 Getting Start 4.1 Install SIM Card Turn off the ZK105L ; - Open ZK105L and insert SMI card as follows Turn on the machine 1Go screw down.
- Page 5 Insert SMI card Find card slot Close the machine...
- Page 6 ZK105L User Manual WCDMA/LTE use: 1 ZK105L can communicate with the backend server through LTE network, and transfer reports of emergency, Geo‐fencing, device status and scheduled GPS position etc… Service provider is easy to setup their tracking platform based on the functional wireless tracking protocol. 2 Device Status LED ZK105L LED Definition No. ...
- Page 7 ZK105L User Manual FCC Certification Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and(2) This device must accept any interference received, including interference that may cause undesired operation.
