Related Manuals for Queclink GT300
Summary of Contents for Queclink GT300
-
Page 1: User Manual
GT300 GSM/GPRS/GPS Tracker User Manual TRACGT300UM002 Revision: 2.03 http://www.queclink.com sales@queclink.com... - Page 2 TRACGT300UM002 General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession.
-
Page 3: Table Of Contents
3. Getting Started ..........................7 3.1. Parts List..........................7 3.2. Battery Charging .........................7 3.3. Install SIM Card ........................8 3.4. Turning GT300 on or off .....................8 3.5. Make a normal call......................8 3.6. Make A Emergency Call......................9 4. Function Menu ..........................10 4.1. Call History ........................10 4.2. -
Page 4: Revision History
GT300 User manual 0. Revision history Revision Date Author Description of change 2.01 2009-08-27 Moon XIE Initial 2.02 2011-04-27 Journey zhang Add Restore Factory Setting 2.03 2011-06-14 Journey zhang Add Silent Auto Answer Setting TRACGT300UM002 - 3 -... -
Page 5: Introduction
GT300 have 4 preset number and a SOS number, user can set the 4 number keys and SOS key though software. By using GT300, user can not only realize SOS alarm, real-time location query and voice call functions but also get the device’s history track though visiting website. -
Page 6: Product Overview
2.2. Keypad and MINI USB Interface Description Keypad Function description Power Key Hold down this key to turn on / turn off GT300 On standby, press this key to lock/unlock the keypad. Volume +/-Key On standby, press this key to Increase or decrease the keypad volume;... -
Page 7: Icon Description
GT300 User manual On standby, hold down this key to switch General and Silent mode. Speed dial On standby, press this key to show the preset contact. 、 、 、 (1 2 3 4) key In menu, press Speed dial 1 or 3 key to page up or down. -
Page 8: Getting Started
If your phone is charged in power off status, charging complete screen will also display. You can also charge the battery by USB cable which connects GT300 with the PC. Charging process usually takes about 3 hours. -
Page 9: Install Sim Card
In order to protect against unlawful usage, the SIM card uses a PIN number. If you insert a SIM in to GT300 which has a PIN Code enabled on it, you must enter the PIN so as to unlock the SIM card before you use GT300. -
Page 10: Make A Emergency Call
GT300 User manual When you want to make a phone call, first press Speed Dial x key, and then press Left soft key to call this preset number. Press end key to end the call while in dialing process. If the call is received, it will be in talking state. -
Page 11: Function Menu
7.2 Controlled Contact 7.3 SIM Contact (optional) 7.4 SOS number Note: SIM Contact menu only shows when GT300 is set to use SIM card contacts function. 4.1. Call History The call History stores the last twenty missed /received /dialed calls. -
Page 12: Check Gps
GPS location acquisition test can be performed by using this option located in the main menu. Press Left soft key to enter the Check GPS.GT300 will search GPS signal and fix location. When GPS positioning is success, the screen will display your location information, including longitude, latitude, speed etc.). -
Page 13: Settings
Restore Factory Setting: The input password is 1122. 4.6. Alarm GT300 can set five alarms at most, and hold out the alarm when the phone is power off. Select one alarm, can set to turn on/off，time , Repeat , Snooze(mins) and Alert Mode. 4.7. Contact Although GT300 only has 4 speed dial keys, it can store a total of 20 numbers in its Controlled Contact. -
Page 14: Troubleshooting And Safety Info
GT300 User manual 5. Troubleshooting and Safety info 5.1. Troubleshooting Trouble Possible Reason Solution Poor reception Using the device in an area with poor Try to avoid reception such as near tall buildings or in a basement where radio waves cannot be transmitted. -
Page 15: Safety Info
GT300 User manual SIM card. Unable to connect Expired SIM card Contact your network provider. with the network Outside the GSM service area Consult your network provider on the service area. Poor signal. Please move to a place with a better signal and try again.
