- Page 1 ZK105M User Manual Document Title ZK105M User Manual Version N/A Author Bruce.Chen Date 2019‐04‐18 Status Release Document Control ID ...
- Page 2 ZK105M User Manual General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession. Furthermore, system validation of ...
- Page 3 ZK105M User Manual Contents Contents ............................2 1 Introduction ............................ 3 2 BLE..............................3 2.1 BLE working modeexplanation .....................3 2.2 BLE instructions ........................3 3 NFC..............................3 3.1 Enable/Disable NFC function ....................3 3.2 NFC Instructions ........................3 4 Tools ( picture ) ..........................4 4.1 Hardware ..........................4 4.1.1 parts list ........................4...
- Page 4 This document describes how the ZK105M enters transparent mode to debug module instructions. The ZK105M Series are a series of water resistant GPS tracker designed for Scooter. Their built-in GPS receiver has superior sensitivity and fast time to first fix (TTFF). Their LTE allows the ZK105M Series' location to be monitored in real time or periodically tracked by a backend server or other specified terminals.
- Page 5 ZK105M User Manual 4 Tools ( picture ) 4.1 Hardware 4.1.1 parts list: Name Picture Debug Cable Table 1.Parts List ...
- Page 6 ZK105M User Manual 4.1.2 I nterface Definition The power cable input 36V, red wire for positive , black wire for negative Getting Start Core function Transmit real time location data to control PCBA of scooter via power cable, speaker be sound when scooter unlock, lock and alarm.
- Page 7 ZK105M User Manual GSM/LTE use: 1 Open the cover of the machine and insert the SIM card; 2 ZK105M can communicate with the backend server through LTE Cat‐M network, and transfer reports of emergency, Geo‐fencing, device status and scheduled GPS position etc… Service provider is easy to setup their tracking platform based on the functional wireless tracking protocol. 3 Device Status LED ...
- Page 8 ZK105M User Manual GPS Specifications Item Parameters GPS Type u-Blox M8130 KT GPS Receiver Tracking & Navigation: -162dBm Reacquisition: -160dBm Sensitivity Coldstart: -147dBm Warm start: -148dBm Hot start:-155dBm GPS without SBAS: <2.5m Position Accuracy (CEP) GPS with SBAS: <2.0m Cold start: 30s average TTFF (Open Sky) Warm start: <28s...
