GT500
GSM/GPRS/WIFI/GPS Tracker

User Manual

TRACGT500UM001
Revision: 1.00
http://www.queclink.com
sales@queclink.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Queclink GT500

  • Page 1: User Manual

    GT500 GSM/GPRS/WIFI/GPS Tracker User Manual TRACGT500UM001 Revision: 1.00 http://www.queclink.com sales@queclink.com...
  • Page 2 Document Control ID General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession.
  • Page 3: Table Of Contents

    GT500 User Manual Contents Contents ........................... 2 0. Revision history ......................3 1. Introduction ........................4 2. Specifications ........................ 5 3. Product Overview......................6 3.1. Appearance ......................6 3.2. Buttons/Mini USB/SIM-Card Interface Description ........... 6 3.3. Lights Description ....................7 4.
  • Page 4: Revision History

    GT500 User Manual 0. Revision history Revision Date Author Description of change 1.00 2012-6-18 Johnson Jiang Initial TRACGT500UM001 - 3 -...
  • Page 5: Introduction

    SOS button. System Integrators can easily communicate with the GT500 by using the @Track protocol. The Wifi access point Mac address reporting will help of accurate in-door location fix with Wifi access.
  • Page 6: Specifications

    GT500 User Manual 2. Specifications GSM/GPS/WIFI Specifications GSM Frequency Quad-Band: 850/900/1800/1900MHz GPS Chipset uBlox All-In-One GPS Receiver Sensitive, Fast and Accurate GPS Sens itivity Cold start: -148dBm Reacquisition : -160dBm Tracking: -162dBm Position Accuracy Autonomous: < 2.5 m SBAS: 2.0 m...
  • Page 7: Product Overview

    GT500 User Manual 3. Product Overview 3.1. Appearance 3.2. Buttons/Mini USB/SIM-Card Interface Description Button /Mini USB Interface Description  Turn on/off GT500. Pow er Button  Two sides buttons to increase / decrease Volume Button volume.  Dial or Reject incoming call.
  • Page 8: Lights Description

    GT500 User Manual 3.3. Lights Description There are four light s in GT500, the description as following. light Eve nt State Battery voltage is lower than 30% Light flash slow ly Charging Light Solid Battery light Charging finished Light Dark...
  • Page 9: Getting Started

     During charging, the battery light is flashing fast. When the battery is full charged, the battery lights will be dark.  You can also charge the battery by USB cable which connects GT500 with the PC.  Charging time is about 4-5 hours.
  • Page 10: Turn On/Turn Off

     Turn off:  Press the Power button until the vibrator is shaking (at least 3 seconds) and release it to turn off GT500 when GT500 is working. At the same time, all light s will be dark. TRACGT500UM001 - 9 -...
  • Page 11: Troubleshooting And Safety Info

     Please do not put the device on the overheating or too humid place, avoid exposure to direct sunlight. Too high temperature will damage the device or even cause the battery explosion.  Please do not use GT500 on the airplane or near medical equipment. TRACGT500UM001...
