Page 1: User Manual
GL300 GSM/GPRS/GPS Tracker User Manual TRACGL300UM001 Revision: Draft http://www.queclink.com sales@queclink.com... - Page 2 Document Control ID General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession.
-
Page 3: Table Of Contents
3. Getting Started ..........................9 3.1. Parts List ..........................9 3.2. Battery Charging ......................... 9 3.3. GL300 External Cable Interface ..................10 3.4. Install SIM Card ........................ 10 3.5. Turn on/Turn off ........................ 11 4. Troubleshooting and Safety info ....................12 4.1. -
Page 4: Revision History
GL300 User Manual 0. Revision history Revision Date Author Description of change Draft 2013-04-18 Tony PEI Initial TRACGL300UM001 - 3 -... -
Page 5: Introduction
GL300 User Manual 1. Introduction GL300 is a powerful GPS Tracker designed for asset, vehicle, and pet tracking. With superior receive sensitivity, fast TTFF (Time to First Fix) and Quad band GSM frequencies 850/900/1800/1900, its location can be continuously monitored or periodically reported to a backend server or other device. -
Page 6: Product Overview
Power Key 2.2. Buttons/Mini USB Interface Description Button /Mini USB Interface Description Turn on GL300 Power Key Turn off GL300 when without charging. (If power key is enabled) Geo-Fence mode Function Key Long press the key to enable/disable Geo-Fence ID0 ... -
Page 7: Leds Description
2.4.1. External DC Charger Interface The Pin2 on Mini-USB connector are used for charging and named as VCHG pin, It can be connected to a 5V DC power supply to power GL300 and charge the internal battery. TRACGL300UM001 - 6 -... -
Page 8: External Battery Interface
The Pin 8 on Mini-USB connector is for external battery and named as EXTBAT pin. It can be connected to 3.7V Li-ion or Li-Polymer battery to power GL300. 2.5. Ignition Detection The Pin 7 on Mini-USB connector is for ignition detection when GL300 is used in vehicle tracking application. It is named as IGN_IND pin. TRACGL300UM001... -
Page 9: External Input Interface
GL300 User Manual Another easy way is to connect PIN7 to a power output in the fuse box of the vehicle which is only enabled after the vehicle is ignition on. For example: the power output for radio FM. 2.6. External Input Interface The Pin 5 on Mini-USB connector is a negative trigger input in newer hardware version. -
Page 10: Getting Started
PWR LED will be Ever-light. You can also charge the battery by USB cable which connects GL300 with the PC. Charging time is about 5 hours. Note: Before the first time using GL300, please full charge the battery. -
Page 11: Gl300 External Cable Interface
GL300 User Manual 3.3. GL300 External Cable Interface GL300 External Cable is a cable with a Mini USB connector and six wires which include the external power interface, ignition detect and input interface for GL300. Please find the detail description in following table. -
Page 12: Turn On/Turn Off
GL300 User Manual 3.5. Turn on/Turn off Turn on: Method 1: Press the Power key at least 3 seconds and release it to turn on GL300. At the same time, will light on. PWR LED Method 2: Connect device to charger or external battery, and it will turn on automatically, will light on. -
Page 13: Troubleshooting And Safety Info
GL300 User Manual 4. Troubleshooting and Safety info 4.1. Troubleshooting Trouble Possible Reason Solution After GL300 is turned on, the The SIM card is not inserted. Please insert the SIM card into GSM LED flashes quickly GL300. always. The signal is too weak;... -
Page 14: Safety Info
Please do not put the device on the overheating or too humid place, avoid exposure to direct sunlight. Too high temperature will damage the device or even cause the battery explosion. Please do not use GL300 on the airplane or near medical equipment. TRACGL300UM001...
