Humanscale QuickStand Eco Installation Instructions Manual page 6

ST EP 9
Adjust the counterbalance system
• Before making any adjustments to the tension, check to see if an adjustment is needed.
• After you have installed all of your peripherals (ie. laptop on surface and/or you have installed your monitor(s), keyboard and
mouse), test the balance of the surface. By grabbing both side edges of the work surface you should be able to seamlessly raise
and lower the platform.
• If the work surface holds its position after you move it — meaning that you don't feel the platform attempting to raise or lower
on its own — then no tension adjustment is needed.
• If the surface does move upward or downward after you change position,
then refer to the information on the next page.
ST EP 9 (CONT INUED)
Scenario A:
Surface lowers on its own without assistance, or lowers
when you place your hands on the keyboard.
• Place the 6mm hex key into the adjustment screw
Step 9
on the top of the column. Turn the adjustment screw
Adjust the counter balance system.
clockwise until the platform holds position and feels
Using the 6mm hex tool, rotate the screw located on the top clockwise
balanced while raising and lowering the work surface.
until forces pushing the keyboard platform up and down becomes about
equal. Clockwise to increase upward force and counter clockwise to lower
upward force.
humanscale.com
For our terms and conditions please go to
https://www.humanscale.com/about/legal-information/terms-conditions.cfm
© 2019 Humanscale Corporation. The text and artwork are copyrighted materials. All rights reserved. The Humanscale mark and logo are trademarks of
Humanscale Corporation and are registered in the United States and certain other countries. The Quickstand Eco trademark is owned by Humanscale.
Corporation.
6
Scenario B:
Surface raises on its own or is difficult to lower.
• Place the 6mm hex key into the adjustment screw
on the top of the column.
Step 9
• Turn the adjustment screw counterclockwise until the
Adjust the counter balance system.
platform holds position and feels balanced while
Using the 6mm hex tool, rotate the screw located on the top clockwise
raising and lowering the work surface.
until forces pushing the keyboard platform up and down becomes about
equal. Clockwise to increase upward force and counter clockwise to lower
upward force.
=
=
