Humanscale QuickStand Eco Installation Instructions Manual page 3

ST EP 1
• Place the base on a desk. Remove
the plastic covers and set them aside.
ST EP 2
• Slide the main post onto the base by inserting the
2 tabs in the front and secure the main post with 6 screws.
• Snap on the plastic covers removed in step 1. Rear cover first, then front cover.
x6
ST EP 3
• Slide the work surface, with preinstalled screw, into the slot in the support bracket.
This will allow you to support the work surface with one hand and use
your other hand to insert and secure the other two screws.
• Tighten all three screws securely with the 6mm hex key.
x2
3
Step 3
The support bracket is slotted, slide the preinstalled screw and work surface
into the slotted position. This will allow you to support the work surface on
the end with one hand and use your other hand to insert and secure the
other two screws. Tighten securely with the 6mm ball pointz allen wrench.
X 3
Step 4
Install the Vesa plate onto the m
