Humanscale QuickStand Eco Installation Instructions Manual page 5

ST EP 6 A (F O R DUA L MONITORS)
• Attach the crossbar to the unit using the 3 screws as shown.
• Attach both monitors to the crossbar.
Refer to the crossbar installation manual.
x2
x1
ST EP 7
• Push the keyboard platform down to remove the lock piece.
WARNING: PINCH POINT POTENTIAL!
KEEP FINGERS CLEAR
DURING OPERATION
ST EP 8
Attach the plastic covers
• Make sure the tabs on the lower plastic cover slide
into the slots in the bracket (see arrows).
• The upper cover slides down from the top, behind the monitor mount bracket.
5
Warning: Pinch Point
