Humanscale Quickstand Installation Instructions

Grommet mount/bolt-through kit

Hide thumbs Also See for Quickstand:

Download this manual

Enlarged version

ST EP 4

Cable Management

•

If running QuickStand cables through the grommet hole in the work surface

install only the front cable tab onto the bottom of the Bolt-Mount (fig. G)

•

If running the QuickStand cables over the back of the work surface install

both cable tabs onto the bottom of the Bolt-Mount (fig. H)

Customer Service:

N America +1 800 400 0625

International +353 (0)1 858 0910

www.humanscale.com

Grommet Mount/Bolt-through Kit

Grommet Mount/Bolt-through Parts

A (1) Grommet Base

B (1) Base Plate

C (2) M8 Flange Nut

D (1) Pair Bolt

Tools Required

E Tape Measure

F 5 mm Hex Key

Need help?

Do you have a question about the Quickstand and is the answer not in the manual?

Page 1 Bolt-Mount (fig. G) • If running the QuickStand cables over the back of the work surface install both cable tabs onto the bottom of the Bolt-Mount (fig. H) Grommet Mount/Bolt-through Kit...
Page 2 5” (127 mm) minimum from the rear of the work surface to the center of • Place the Bolt-Mount onto the QuickStand base and position it so that the the grommet hole. (fig. A) distance between the front edge of the platform to the center of the pair-bolt •...
