Freestanding Base

I N STA L L AT IO N IN ST R U C T I ONS

PA RT S R EQUIR ED

(1) QuickStand Unit

(2) Leg-Covers

(1) Stopper

(1) Leg

(1) Base

(1) Spacer

(1) Platform (work surface)

(8) M6 x 9.5 mm Flat Head Machine Screws

(6) M8 x 18 mm Flat Head Machine Screws

(2) M8 x 14 mm Button Head Machine Screws

4 mm Hex Key (supplied)

5 mm Hex Key (supplied)

6 mm Hex Key (supplied)

Hardware

Table of Contents

Need help?

Do you have a question about the QuickStand and is the answer not in the manual?

Page 1 Freestanding Base I N STA L L AT IO N IN ST R U C T I ONS PA RT S R EQUIR ED (1) QuickStand Unit (2) Leg-Covers (1) Stopper (1) Leg (1) Base (1) Spacer (1) Platform (work surface) (8) M6 x 9.5 mm Flat Head Machine Screws...
Page 2 Failure to comply with the instructions provided may result in property damage or serious injury. Do not remove bracing box attached to QuickStand unit until your QuickStand is fully assembled...
Page 3 (fig. E) • Using the (2) M8 x 10 mm Cap Head Machine Screws and the Washers from step 1, secure the Platform to the QuickStand unit ST EP 4 Attaching Spacer Under the Platform •...
Page 4 (fig K) Proceed to the Monitor Installation steps in the main QuickStand Assembly Instructions Customer Service: N America +1 800 400 0625 / International +353 (0)1 858 0910...
