8. Use the supplied accessories to help locate and retrieve small items (BR200 and BR250
only). Refer to the separate section in this manual for connecting the attachment
accessories.

Capturing still images

Use the up arrow button on the Monitor to select the Image
capture a still image. The image will automatically save to the SD card.

Recording video

Use the up arrow button on the Monitor to select Video
recording; refer to the following diagram for display icon descriptions:
1. Battery capacity
2. Function icon (video/image)
3. Recording in progress
4. ZOOM level
5. Date and Time
6. Recording time remaining
7. SD card status
Playback: Viewing images and video on the monitor
1. Press to display a list of playback folders sorted by date
2. Use the▼▲buttons to select a folder
3. Press OK to open the selected folder and view the list of
images and/or video files contained in the folder
4. Files are sorted by time of day; image files are in JPG format
and video files are in MP4 format
5. Use the ▼▲buttons to select a file
6. Press OK to display the selected image or video.
For video files: Press OK to pause and resume
▲ Fast Forwards the video; ▼ Rewinds the video
Press to stop video
7. Press to return to menu
8. Press again to exit
Note: Video automatically saves to a file on the SD card every 30 minutes. When the SD card is
filled to capacity, the SD card icon changes to 'F'. No images or video can be recorded if the SD
card is not inserted in the slot or if the SD card has reached maximum capacity.
mode, and then press OK to
mode, and then press OK to begin
