Restoring Factory Default Settings

1. In the Settings Menu, use▼▲buttons to select the System setting (green icon)
2. Press OK to call up the System icon list
3. Use the arrows to highlight the DEFAULT icon (red)
4. Press OK and the DEFAULT selection screen will appear (YES, NO)
5. Use the arrows to highlight YES (factory default) or NO (leave unchanged)
6. Press OK to accept the selection
7. Press the
another icon in the System settings menu

View Version

1. In the Settings Menu, use▼▲buttons to select the System setting (green icon)
2. Press OK to call up the System icon list
3. Use the arrows to highlight the VERSION icon (green)
4. Press OK to view the version
5. Press OK again to exit
6. Press the
another icon in the System settings menu

Frame Rate Setting

1. In the Settings Menu, use the▼▲buttons to select Recorder settings (red icon)
2. Press OK to call up the Recorder options
3. Use the arrows to highlight the FPS (frames per second) icon (green)
4. Press OK to open the FPS parameter
5. Use the arrows to select the frame rate: 10, 15, 20, 25, or 30
6. Press OK to confirm
7. Press the
another icon in the Recorder settings menu
Time Stamp ON/OFF Setting
1. In the Settings Menu, use the▼▲buttons to select Recorder settings (red icon)
2. Press OK to call up the Recorder options
3. Use the arrows to highlight the Time Stamp icon (purple)
4. Press OK to open the parameter
5. Use the arrows to select ON or OFF
6. Press OK to confirm
7. Press the
another icon in the Recorder settings menu
button to return to the main Settings Menu or use the arrows to move to
button to return to the main Settings Menu or use the arrows to move to
button to return to the main Settings Menu or use the arrows to move to
button to return to the main Settings Menu or use the arrows to move to
11
