Capturing still images

Recording video

Playback: Viewing images and video on the monitor
Find Quality Products Online at:
8. Use the supplied accessories to help locate and retrieve small items (BR200 and BR250
only). Refer to the separate section in this manual for connecting the attachment
accessories.
Use the up arrow button on the Monitor to select the Image
capture a still image. The image will automatically save to the SD card.
Use the up arrow button on the Monitor to select Video
recording; refer to the following diagram for display icon descriptions:
1. Battery capacity
2. Function icon (video/image)
3. Recording in progress
4. ZOOM level
5. Date and Time
6. Recording time remaining
7. SD card status
1. Press to display a list of playback folders sorted by date
2. Use the buttons to select a folder
3. Press OK to open the selected folder and view the list of
images and/or video files contained in the folder
4. Files are sorted by time of day; image files are in JPG format
and video files are in MP4 format
5. Use the buttons to select a file
6. Press OK to display the selected image or video.
For video files: Press OK to pause and resume
Fast Forwards the video;
Press to stop video
7. Press to return to menu
8. Press again to exit
Note: Video automatically saves to a file on the SD card every 30 minutes. When the SD card is
card is not inserted in the slot or if the SD card has reached maximum capacity.
GlobalTestSupply
www.
mode, and then press OK to begin
Rewinds the video
F images or video can be recorded if the SD
