SECTION 6
_______________________________________________________________________
Replacing the PIC cable is an important routine maintenance action which will improve the
reliability of the BIS monitoring system.
6.3

System Checkout

A system checkout should be done periodically to verify that all system components are in
working order. To test the system from the BISx to the BIS sensor, you will need a Sensor
Simulator (P/N 186-0137) or a Test Sensor (See Appendix I for more information). Follow
the instructions below for System Checkout.

6.3.1 Monitor Checkout Procedure

The successful completion of this test will verify that the monitor is functioning and that all
operator input (soft keys) and output (display and audio alarm) are OK.
IF ANY FAILURES ARE NOTED, SEE SECTION 7.3, "BIS
VIEW System Messages And Corrective Actions".
1. Disconnect the BISx from the monitor.
2. Connect power cord to monitor. Plug power plug into appropriate wall outlet.
• Verify that the light to the right of the ON/Standby button is yellow.
3. Start up monitor by pressing the ON/Standby button (lower right corner).
• Verify that the light to the right of the ON/Standby button is green.
• Verify all self-tests complete successfully. A beep tone sounds.
• Verify next screen says "Connect BISx."
4. Connect BISx to monitor with PIC and sensor.
• Verify screen says, "BISx Initialization Complete."
• Verify SENSOR CHECK begins. (Note that if a BIS Extend Sensor is attached,
you must press [CONTINUE] to proceed to the Sensor Check.)
5. Disconnect power cord from monitor.
• Verify 'OPERATING ON BATTERY BACKUP' is displayed.
• Verify battery icon displays below BIS number.
Since the BIS VIEW monitor has a built in battery backup, the monitor will power up with
or without AC power applied. This step assures that this part of the test is performed under
battery power
6. Reconnect power cord.
• Verify battery icon is not displayed below BIS number.
• Verify 'OPERATING ON BATTERY BACKUP is not displayed.
PREVENTIVE MAINTENANCE
NOTE:
6-2
