PROJECTION MONITOR
Operating Guide for
51M200, 65M200, 51M200A
IMPORTANT SAFETY INSTRUCTIONS ................................................................................ 2-3
FIRST TIME USE .................................................................................................................. 4-19
THE REMOTE CONTROL .................................................................................................. 20-30
ON-SCREEN DISPLAY........................................................................................................ 31-52
USEFUL INFORMATION .................................................................................................... 54-57
INDEX ........................................................................................................................................58

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 51M200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aspect 51M200

Summary of Contents for Aspect 51M200

  • Page 1: Table Of Contents

    PROJECTION MONITOR Operating Guide for 51M200, 65M200, 51M200A IMPORTANT SAFETY INSTRUCTIONS ... 2-3 FIRST TIME USE ... 4-19 THE REMOTE CONTROL ... 20-30 ON-SCREEN DISPLAY... 31-52 CARE OF YOUR ASPECT PROJECTION MONITOR AND REMOTE CONTROL ...53 USEFUL INFORMATION ... 54-57...

  • Page 2: Important Safety Instructions

    SAFETY POINTS YOU SHOULD KNOW ABOUT YOUR ASPECT PROJECTION MONITOR Our reputation has been built on the quality, performance, and ease of service of ASPECT Projection Monitors. Safety is also foremost in our minds in the design of these units. To help you operate these products properly, this section illustrates safety tips which will be of benefit to you.
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS Read before operating equipment Follow all warnings and instructions marked on this Projection Monitor. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6.

  • Page 4: First Time Use

    Check to make sure you have the following accessories before disposing of the packing material. 1. Remote Control Unit is either CLU-4330UG (Part No. HL02251). 2. Two “AA” size, 1.5V batteries (For Remote Control Unit). REMOTE CONTROL BATTERY INSTALLATION AND REPLACEMENT 1.
  • Page 5 HOW TO SET UP YOUR NEW HITACHI PROJECTION MONITOR LOCATION Select an area where sunlight or bright indoor illumination will not fall directly on the picture screen. Also, be sure that the location selected allows a free flow of air to and from the perforated back cover of the set. To avoid cabinet warping, cabinet color changes, and increased chance of set failure, do not place the Projection Monitor where temperatures can become excessively hot, for example, in direct sunlight or near a heating appliance, etc.

  • Page 6: Hook-Up Cables And Connectors

    Most video/audio connections between components can be made with shielded video and audio cables that have phono connectors. For best performance, video cables should use 75-Ohm coaxial shielded wire. Cables can be purchased from most stores that sell audio/video products. Below are illustrations and names of common connectors. Before purchasing any cables, be sure of the output and input connector types required by the various components and the length of each cable.

  • Page 7: Front Panel Controls

    FRONT INPUT JACKS (INPUT 5) Use these audio/video jacks for a quick hook-up from a camcorder or VCR to instantly view your favorite show or new recording. Press the INPUT button until VIDEO: 5 appears in the top right corner of the Projection Monitor screen. If you have mono sound, insert the audio cable into the left audio jack.
  • Page 8 The front panel jacks are provided as a convenience to allow you to easily connect a camcorder or VCR as shown in the following examples: -AUDIO- INPUT 5 S-VIDEO VIDEO L/MONO 1. Completely insert connection cord plugs when connecting to front panel jacks. If you do not, the played back picture NOTE: may be abnormal.

  • Page 9: Rear Panel Jacks

    REAR PANEL JACKS IMPORTANT: This is a monitor only product. No TV or Cable tuner is included. AUDIO TO HI-FI Audio/Video Inputs 1, 2, 3 and 4 The VID1~VID4 buttons will select each video source each time they are pressed. Use the audio and video inputs to connect external devices, such as VCRs, camcorders, laserdisc players, DVD players etc.
  • Page 10 Component: Y-P Inputs Inputs 1 and 2 provide Y-P jacks for connecting equipment with this capability, such as a DVD player or Set Top Box. You may use composite video signal for INPUT:2. 1. Do not connect composite VIDEO and S-VIDEO to Input 3, 4 or 5 at the same time. S-VIDEO has priority over VIDEO NOTES: input.

  • Page 11: Rear Panel Connections

    DVI-HDTV INPUT 1 (MONO)/L AUDIO Y/VIDEO INPUT 2 (MONO)/L AUDIO (MONO)/L VIDEO S-VIDEO INPUT 3 (MONO)/L VIDEO S-VIDEO INPUT 4 VIDEO S-VIDEO MONITOR AUDIO S-VIDEO INPUT VCR #2 D-VHS DIGITAL OUTPUT OUTPUT S-VIDEO OUTPUT Laserdisc player, VCR, camcorder , etc.

  • Page 12: Tips On Rear Panel Connections

    You may use VIDEO or S-VIDEO inputs to connect to Input 3, Input 4 or Input 5, but only one of these may be used at a time. • Connect only 1 component (VCR, DVD player, camcorder, etc.) to each input jack. •...

  • Page 13: Connecting External Audio Devices

    CONNECTING EXTERNAL AUDIO DEVICES To control the audio level of an external audio amplifier with the remote control, connect the system as shown below. INPUT Stereo SystemAmplifier To prevent damage to the speaker and distorted sound, set the volume control of the audio amplifier lower and adjust NOTE: the sound using the remote control of the Projection Monitor.

  • Page 14: Connecting External Video Sources

    The exact arrangement you use to connect the VCR, camcorder, laserdisc player, DVD player, or HDTV Set Top Box to your Projection Monitor is dependent on the model and features of each component. Check the owner’s manual of each component for the location of video and audio inputs and outputs.
  • Page 15 CONNECTING EXTERNAL VIDEO SOURCES CONNECTING A MONAURAL AUDIO SOURCE TO INPUT1~INPUT5 Connect the cable from the VIDEO OUT of the VCR or the laserdisc player to the INPUT (VIDEO) jack, as shown on the Projection Monitor below. Connect the cable from the AUDIO OUT of the VCR or the laserdisc player to the INPUT (MONO)/L(AUDIO) jack. Press the VID4 button to view the program from the VCR or the laserdisc player.
  • Page 16 CONNECTING A STEREO SOURCE TO INPUT1~INPUT5 Connect the cable from the VIDEO OUT of the VCR or the laserdisc player to the INPUT (VIDEO) jack, as shown on the Projection Monitor below. Connect the cable from the AUDIO OUT R of the VCR or the laserdisc player to the INPUT (AUDIO/R) jack. Connect the cable from the AUDIO OUT L of the VCR or the laserdisc player to the INPUT (AUDIO/L) jack.
  • Page 17 CONNECTING EXTERNAL VIDEO SOURCES CONNECTING AN S-VIDEO SOURCE TO INPUT 3, 4 AND 5 Connect the cable from the S-VIDEO OUT of the VCR or the laserdisc player to the INPUT (S-VIDEO) jack, as shown on the Projection Monitor below. Connect the cable from the AUDIO OUT R of the VCR or the laserdisc player to the INPUT (AUDIO/R) jack.
  • Page 18 CONNECTING A COMPONENT SOURCE WITH DVI-HDTV CAPABILITY TO INPUT 1. Connect the DVI connection cable from the output of the HDTV set top box or DVD player to the DVI-HDTV input as shown on the Projection Monitor below. Connect the cable from the AUDIO OUT R of the HDTV set top box or DVD player to the INPUT (AUDIO/R) jack. Connect the cable from the AUDIO OUT L of the HDTV set top box or DVD player to the INPUT (AUDIO/L) jack.
  • Page 19 CONNECTING EXTERNAL VIDEO SOURCES CONNECTING A COMPONENT SOURCE TO INPUT 1 OR 2: Y-P B P R . Connect the cable from the Y OUT of the Laserdisc/DVD player or HDTV set top box to the INPUT (Y) jack, as shown on the Projection Monitor below.

  • Page 20: The Remote Control

    In addition to controlling all the functions on your ASPECT Projection Monitor, the new remote control is designed to operate dif- ferent types of VCRs, CBL (Cable TV) converters, satellite receivers, DVD players, and other audio/video equipment. Basic oper- ation keys are grouped together in one area. To operate your Projection Monitor, point the remote control at the IR Receiver sensor (see page 7) of the Projection Monitor and press the TV button.
  • Page 21 HOW TO USE THE REMOTE TO CONTROL YOUR PROJECTION MONITOR PROJECTION MONITOR POWER button PICTURE-IN-PICTURE DAY/NIGHT button SELECT, MENU, CURSOR buttons VOLUME, MUTE buttons CHANNEL SELECTOR buttons ANT button VID1~VID5 buttons POWER button Press this button to turn the Projection Monitor on or off when the remote is in TV (Monitor) mode. PICTURE-IN-PICTURE buttons See separate section on pages 25, 26 and 27 for description.
  • Page 22 VOLUME, MUTE button Press the VOLUME up ( ) or down ( ) button until you obtain the desired sound level. To reduce the sound to one half the normal volume (SOFT MUTE), press the MUTE button. Press the MUTE button again to turn the sound off completely (MUTE).
  • Page 23 HOW TO USE THE REMOTE TO CONTROL YOUR PROJECTION MONITOR SIZE button Press this button to quickly change the picture format SIZE ratio. Depending on the input signal, the picture format ratio allows you to adjust the images through the following options. 4:3 Standard Use this size mode to display conventional (4:3) images.
  • Page 24 SLEEP button Show and set your SLEEP timer for up to 3 hours in 15 minute intervals. --:-- Zzzz INFO button Press this button when you want to check the channel being received, the picture source, if the channel has stereo (ST) or second audio program (SAP), the time and CHANNEL ID.

  • Page 25: Picture In Picture (Pip)

    PICTURE-IN-PICTURE (PIP) All Video inputs can be viewed as both the main picture and the sub-picture simultaneously. To select between main picture and PIP sub-picture tuning, press the SWAP button on the remote. The green highlighted Video input display will move with every press of the SWAP button.
  • Page 26 SPLIT MODE PICTURE-IN-PICTURE Split Mode PIP displays the main picture and sub-picture evenly on the screen. Main Picture SWAP button If you wish to enable the Audio from the Main Picture to the Sub-Picture, press the SWAP button. Video: 3 SPLIT Green Highlight The SWAP button will only operate in POP/SPLIT/PIP mode.

  • Page 27: Main Picture

    PICTURE-IN-PICTURE (PIP) FREEZE button (With PIP ON) If you wish to freeze the sub-picture, press the FREEZE button. This is convenient when trying to write down the address for a mail order company, recording statistics for a sporting event, etc. To return the picture to motion, press the FREEZE button again.

  • Page 28: Using The Remote To Control Vcr Functions

    Aiwa ........48 Daewoo ........45 Emerson .
  • Page 29 USING THE REMOTE TO CONTROL CABLE/SATELLITE BOX FUNCTIONS Operating the precoded function for your cable/satellite box. This remote is designed to operate different types of cable/satellite boxes. You must first program the remote to match the remote sys- tem of your cable/satellite box . Turn ON your cable/satellite box.
  • Page 30 Operating the precoded function for your DVD player. This remote is designed to operate different types of DVD players. You must first program the remote to match the remote system of your DVD player. Turn ON your DVD player. Aim the remote control at the front of your DVD player. Press and release the DVD/VCR button to switch to DVD pre-coded mode.

  • Page 31: On-Screen Display

    ON-SCREEN DISPLAY (OSD) 1. Press MENU on the remote control to display the different features on your ASPECT Projection Monitor. 2. Press the CURSOR 3. Press EXIT on the remote control to quickly exit from a menu. 4. Press CURSOR to access Favorite Channels menu.
  • Page 32 Picture Mode Contrast Brightness Color Tint Sharpness Color Temperature Video Black Enhancement Edge Enhancement Reset Video Settings Color Management Color Decoding Auto Color Noise Reduction Auto Movie Mode Treble Bass Balance Audio Sound Enhancement Internal Speakers Perfect Volume Loudness Aspect Mode Change Access Code Engage Lock...

  • Page 33: Picture Mode

    VIDEO Select VIDEO to adjust picture settings and improve picture quality. You can independently customize each of the Video Video Inputs to your preference to increase viewing performance and pleasure depending upon the video program being viewed. If RESET is selected, only the selected input will reset to initial conditions. Picture Mode Use this function to choose from automatic picture settings to optimize your Projection Monitor’s performance.
  • Page 34 Video Audio Aspect Locks Setup MENU Move Use the CURSOR to highlight the function to be adjusted. Press the SELECT button to select the function settings. Press the CURSOR to adjust the function. Press MENU to return to main menu. Press EXIT to quit menu.
  • Page 35 VIDEO This function allows you to Reset the Video Menu Settings of the present input and return it to the Day VIDEO Reset Video mode. Settings Video Picture Mode Contrast Brightness Color Tint SELECT Sharpness Color Temperature Black Enhancement Edge Enhancement Reset Video Settings Move Select...
  • Page 36 Use this function to adjust the percentage of Red, Green and Color according to the user’s preference. Color Decoding Use TINT to adjust flesh tones so they appear natural. Video Color Management Color Decoding Auto Color Noise Reduction Auto Movie Mode Move Select Use CURSOR to highlight function.
  • Page 37 AUDIO Select AUDIO to adjust the Projection Monitor to your preference and to improve the sound quality. Audio Video Audio Aspect Locks Setup MENU Move Press CURSOR to select menu item. Press CURSOR to adjust the function. Press EXIT to quit the MENU, or select AUDIO to return to the main menu. If TREBLE is selected you are adjusting treble.
  • Page 38 The following surround settings will reproduce the “live” sound you would hear in concert halls, Sound Enhancement sports stadiums, movie theaters, etc. with only two speakers. Video Audio Aspect Locks Setup MENU Move To enter SOUND ENHANCEMENT, use CURSOR your choice (Off, SRS, BBE and SRS and BBE). Use the CURSOR to highlight your sound enhancement choice, and press SELECT to select your choice.

  • Page 39: Aspect Mode

    ASPECT Aspect Mode Use this function to select the Picture Format Aspect Ratio (SIZE). Video Audio Aspect Locks Setup MENU Move Auto Aspect Automatically adjust the Aspect Ratio depending on the input signal to fill the screen. Press CURSOR to select menu item. Press the SELECT button to select.
  • Page 40 This function is only available if used in conjunction with an external tuner. This function will block out Locks the picture and sound of the selected channel or video input. It can also be used to keep the Projection Monitor from being viewed for a scheduled time period that you set. The code to enter the Locks feature is a four digit secret code number.
  • Page 41 LOCKS Use MOVIE RATINGS to prevent viewing of any movie that you feel may be inappropriate due to Movie Ratings its content. Locks Change Access Code Engage Lock Movie Ratings TV Ratings MENU Canadian Ratings (Eng) Canadian Ratings (Frn) Move Select Use CURSOR to select the MOVIE RATING category that you want to block.
  • Page 42 Use TV RATINGS to prevent the viewing of any TV program that you feel may be inappropriate TV Ratings due to its content. Locks Change Access Code Engage Lock Movie Ratings TV Ratings MENU Canadian Ratings (Eng) Canadian Ratings (Frn) Move Select Use CURSOR...
  • Page 43 LOCKS Use CANADIAN RATINGS (ENG) to block any type of movie and television program in Canada Canadian Ratings that you feel might be inappropriate in its content. (Eng) Locks Change Access Code Engage Lock Movie Ratings TV Ratings MENU Canadian Ratings (Eng) Canadian Ratings (Frn) Move Select...
  • Page 44 Use CANADIAN RATINGS (FRN) to block Canadian French programs according to various pro- Canadian Ratings gram ratings that you feel might be inappropriate in its content. (Frn) Locks Change Access Code Engage Lock Movie Ratings TV Ratings MENU Canadian Ratings (Eng) Canadian Ratings (Frn) Move Select...
  • Page 45 SETUP Select SETUP when setting your Projection Monitor up for the first time. Use the CURSOR Setup to highlight the function desired. Video Audio Aspect Locks Setup MENU Move Use CURSOR to select the sub-menu of your choice. Setup Magic Focus Tune Up Menu Preference Set The Clock Set The Inputs...
  • Page 46 Magic Focus Tune Up Auto Digital Convergence Adjustment Please turn ON your Projection Monitor for at least 20 minutes before using this feature. The Magic Focus button on control panel will not work when adjustment mode is set to Manual (see page 47). Your ASPECT Projection Monitor has three color projection tubes: one for red, one for green, one for blue.
  • Page 47 SETUP Manual Convergence Adjustment Mode NOTES: 1. Please turn ON your Projection Monitor for at least 20 minutes before using this feature. 2. Auto Adjustment Mode is recommended. If convergence is still not acceptable, use the Manual Adjustment Mode. 3. If Auto Adjust mode is selected or the Magic Focus button is pressed, all manual adjust mode settings will be erased. Using the Remote Control, select SETUP-MAGIC FOCUS TUNE UP-MANUAL ADJUSTMENT MODE-START to access convergence crosshatch pattern.

  • Page 48: Menu Preference

    Menu Preference This feature will allow you to select any one of three different languages for all on-screen displays. Setup Magic Focus Tune Up Menu Preference Set The Clock Set The Inputs MENU Set The Color System Set Virtual HD Set Black Side Panel Set Closed Caption About Your TV...
  • Page 49 SETUP This function allows you to choose from two menu backgrounds. Menu Background Use CURSOR to highlight SET THE MENU BACKGROUND (shaded or solid), and press the SELECT button to select setting. Press EXIT to quit menu or CURSOR Select SOLID for a black background (no picture can be seen behind menu screen), or select SHADED for a light background. Set The Clock The clock must be adjusted before you can use the “Set Event Timer”...
  • Page 50 Set The Inputs Use this feature to give a name to any of the five video inputs. Setup Magic Focus Tune Up Menu Preference Set The Clock Set The Inputs MENU Set The Color System Set Virtual HD Set Black Side Panel Set Closed Caption About Your TV Move...
  • Page 51 SETUP This function allows you to automatically change tint and color coordinates for DTV programs. Set The Color HDTV - High Definition Television - Use for High Vision Signal Y-P System SDTV/DVD - Standard Definition Television or DVD (Digital Versatile Disc Player) Y-C NOTES: 1.

  • Page 52: About Your Tv

    Closed Captions are the dialogue, narration, and/or sound effects of a television program or home video Set Closed which are displayed on the Projection Monitor screen. Your local TV program guide denotes these programs Caption Setup Magic Focus Tune Up Menu Preference Set The Clock Set The Inputs...

  • Page 53: Care Of Your Aspect Projection Monitor And Remote Control

    CARE OF YOUR ASPECT PROJECTION MONITOR AND YOUR REMOTE CONTROL Dust the screen and cabinet with a soft cloth. Clean the screen with a soft cloth moistened in warm water and dry with a soft cloth. A mild soap may be used if the screen is extremely dirty.

  • Page 54: Reception Problems

    The Projection Monitor can generate sound distortion in external devices such as a radio. Please separate radio equip- NOTE: ment from the Projection Monitor set to a considerable distance. • IGNITION NOISE: Black spots or horizontal streaks may appear, picture may flutter or drift. Usually caused by interference from automobile ignition systems, neon lamps, electrical drills, and other electrical appliances.

  • Page 55: Useful Info

    USEFUL INFO SYMPTOMS No Picture, no sound Sound OK, picture poor Picture OK, sound poor Picture blurred Lines or streaks in picture Picture rolls vertically No color Poor color ASPECT Projection Monitor incorporates advanced power surge protection technology designed to protect against component or circuit damage due to external or internal voltage power surges.
  • Page 56 Video ..... . .1.0Vp-p. 75 Ohm • Audio (Fixed) ....470mVrms, 1k Ohm Dimensions: 51M200 51M200A • Height (in.)
  • Page 57 USEFUL INFO ASPECT Brand Electronics ASPECT has made every effort to assure you hours of trouble free operation from your unit. However, should you require serv- ice, a network of ASPECT Authorized Service Facilities has been established in all 50 states and Puerto Rico. Each facility will provide you with convenient and expedient assistance.

  • Page 58: Index

    Accessories, 4 Aspect Ratio, 23 Audio (Sound Enhancement) SRS, 38 BBE, 38 Audio Settings, 37 - 38 Auto Color, 36 Balance, 37 Bass, 37 Black Enhancement, 34 Black Side Panel, 51 Brightness, 34 Clock Time, 49 Closed Captions Captions, 52 Color Management, 35 Color Temperature, 34 Color, 34...
  • Page 59 NOTES...
  • Page 60 NOTES...
  • Page 61 NOTES...
  • Page 62 NOTES...
  • Page 63 NOTES...
  • Page 64 QR64461...

This manual is also suitable for:

65m20051m200a51m200om

Table of Contents
