Technical Specifications - H3C SecPath F100-C-EI Quick Start Manual

Quick Start
H3C SecPath F100-C-EI Firewall

1.2 Technical Specifications

Table 1-1 Technical specifications of the F100-C-EI
Specifications
Interface
SDRAM
Flash memory
Rated voltage range
Maximum input current
Power consumption
Dimensions (W x H x D)
Weight
Operating temperature
Relative humidity
Chapter 1 Firewall Overview
1 console port
1 × 10/100 Mbps Ethernet interface
4 × 10/100 Mbps Ethernet ports (LAN
and WAN)
Default: 64 MB
Max: 64 MB
8 MB
100 VAC to 240 VAC, 50 Hz or 60 Hz
0.4 A
6 W to 8 W
230 × 43.6 × 200 mm (9.06 × 1.82 ×
7.87 in., excluding foot pads)
2 kg
0°C to 45°C (32°F to 113°F)
10% to 95% (noncondensing)
1-3
Item
